R-428JK
R-428JW
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
PARTS LIST
Note: The parts marked “
∆∆
∆∆
∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V. "§" MARK: PARTS DELIVERY SECTION.
∆
ELECTRIC PARTS
1- 1 RC-QZB018MRE0 M High voltage capacitor 1 AQ
1- 2 FH-DZB013MRY0 M High voltage rectifier assembly 1 AM
1- 3 RLMPTA087WRZZ M Oven lamp/socket 1 AE
1- 4 RMOTEA346WRE0 M Fan motor 1 AR
1- 5 FFS-BA019/KIT M
Monitor switch (V-16G-2C25), C/T fuse (20A 250V AC) & Inst.
1AF
1- 6 QSW-MA085WRE0 M
Primary interlock switch and door sensing switch (V-5230Q)
2AE
1- 7 QFS-TA014WRE0 M Cavity temperature fuse 150
O
C 1AF
1- 8 RV-MZA323WRZZ M Magnetron 1 AZ
1- 9 RMOTDA252/KIT M Turntable motor 1 AL
1-10 RTRN-B075MRE0 M Power transformer 1 BA
1-11 FACCDB003MRE0 M Power supply cord 1 AM
1-12 FDTCTA198WRK0 M AH Sensor 1 AN
CABINET PARTS
2- 1 GDAI-B069MRP0 M Base plate 1 AP
2- 2 GLEGPB004MRF0 M Foot 4 AB
2- 3 GCABUB092MRP0 M Outer case cabinet [R-428JK] 1 AU
2- 3 GCABUB093MRP0 M Outer case cabinet [R-428JW] 1 AU
CONTROL PANEL PARTS
3- 1 CPWBFB094MRU0 M Control unit assy 1 BF
3- 2 HPNLFB010MRF0 M Control panel sub assembly [R-428JK] 1 AN
3- 2 HPNLFB011MRF0 M Control panel sub assembly [R-428JW] 1 AN
3- 3 FUNTKB407MRE0 M Key sheet assy[R-428JK] 1 AS
3- 3 FUNTKB408MRE0 M Key sheet assy[R-428JW] 1 AS
3- 4 JBTN-B173MRT0 M Open button 1 AM
3- 5 MSPRCA045WRE0 M Open button spring 1 AA
3- 6 XEPSD30P08XS0 M Screw; 3mm x 6mm 5 AB
3- 7 HDECQB051MRT0 M C/P J-Mold 1 AL
3- 8 PCOVPB112MRF0 M Night light cover 1 AD
3- 9 QCNC-A020WRZZ M Rubber connector 1 AC
3-10 HPNLCB179MRF0 M Key fixing mold 1 AL
3-11 PSHEPA900WREZ M LED sheet 1 AG
3-12 RLCDSA107DRZZ M LCD 1 AG
3-13 LANGQB060MRP0 M PWB support angle 1 AE
OVEN PARTS
4- 1 LBNDKB007MRP0 M H.V. Capacitor band 1 AB
4- 2 LANGTB058MRP0 M Chassis support 1 AD
4- 3 PHOK-B018MRF0 M Latch hook 1 AF
4- 4 MLEVPB016MRF0 M Switch lever 1 AD
4- 5 PDUC-B125MRF0A M Magnetron duct 1 AD
4- 6 NFANPB006MRE0 M Fan blade 1 AC
4- 7 PDUC-B088MRF0 M Fan duct 1 AC
4- 8 ------------- M Oven cavity (Not a replaceable part) 1 --
4- 9 PCOVPB085MRP0 M Waveguide cover 1 AH
4-10 PPACGB014MRF0 M Turntable motor packing 1 AA
4-11 PCUSUB033MRP0 M Cushion 1 AD
4-12 PDUC-B106MRP0 M Sensor duct 1 AG
DOOR PARTS
5 -1 FCOV-B260MRK0 M Door frame assembly [R-428JK] 1 AV
5 -1 FCOV-B261MRK0 M Door frame assembly [R-428JW] 1 AV
5 -2 LSTPPB021MRF0 M Latch head 1 AD
5 -3 MSPRTA046WRE0 M Latch spring 1 AD
5 -4 FDORFB074MRT0 M Door panel 1 AQ
5 -5 PSHEPB021MRE0 M Sealer film 1 AE
5- 6 GCOVHB046MRF0 M Choke cover 1 AG
5- 7 LSTPPB044MRF0 M Door stopper 1 AA
5- 8 HPNL-B112MRE0 M Door screen 1 AN
5- 9 HDECQB050MRT0 M J-mold 1 AX
