24
R-430CK
R-430CW
R-430CD
93 AN2 IN To input signal which communicates the door open/close information to LSI.
Door close "H" level signal (0V). Door open "L" level signal (-5V).93
83-85 AN3 IN Terminal not used.
83-85 AN4 OUT Terminal not used.
96-98 AN5-AN7 IN Terminal to change cooking input according to the Model.
By using the A/D converter contained in the LSI, DC voltage in accordance with the Model
in operation is applied to set up its cooking constant.
99 AN8 IN Input terminal to judge the model.
The signal will be input into AN8 through one of G1 - G8 lines on key matrix. The LSI will
judge the model by this signal.
100 P41 IN Signal similar to AN10.
When either G11 line on key matrix is touched, a corresponding signal will be input into AN9.
Pin No. Signal I/O Description
