46
R-430DK
R-430DW
R-430DQ
R-440DK
R-440DW
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
3- 2- 2 JBTN-B094MRF0 M Open button [R-430DK & R-440DK] 1 AE
3- 2- 2 JBTN-B095MRF0 M Open button [R-430DW & R-440DW] 1 AE
3- 2- 2 JBTN-B096MRF0 M Open button [R-430DQ] 1 AE
3- 2- 3 MSPRTA050WRE0 M Open button spring 1 AA
3- 3 LHLD-B013MRF0 M LCD holder 1 AF
3- 4 PSHEPB027MRE0 M LED sheet 1 AF
3- 5 XEPSD30P10XS0 J Screw; 3mm x 10mm [R-430DK/DW/DQ] 3 AA
3- 5 XEPSD30P10XS0 J Screw; 3mm x 10mm [R-440DK/DW] 5 AA
OVEN PARTS
4- 1 LBNDKB007MRP0 M H.V. Capacitor band 1 AB
4- 2 LANGTB048MRP0 M Chassis support 1 AE
4- 3 PHOK-B018MRF0 M Latch hook 1 AF
4- 4 MLEVPB016MRF0 M Switch lever 1 AD
4- 5 PDUC-B104MRF0 M Magnetron duct 1 AF
4- 6 NFANPB006MRE0 M Fan blade 1 AC
4- 7 PDUC-B088MRF0 M Fan duct 1 AC
4- 8 ------------ M Oven cavity (Not a replaceable part) 1 --
4- 9 PCOVPB085MRP0 M Waveguide cover 1 AD
4- 10 PPACGB014MRF0 M Turntable motor packing 1 AA
4- 11 PDUC-B106MRP0 M AH sensor duct 1 AG
4- 12 PCUSGB033MRP0 M Cushion 1 AA
DOOR PARTS
5 -1 FCOV-B156MRK0 M Door frame assembly [R-430DK] 1 AQ
5 -1 FCOV-B157MRK0 M Door frame assembly [R-430DW] 1 AQ
5 -1 FCOV-B158MRK0 M Door frame assembly [R-430DQ] 1 AQ
5 -1 FCOV-B168MRK0 M Door frame assembly [R-440DK] 1 AQ
5 -1 FCOV-B169MRK0 M Door frame assembly [R-440DW] 1 AQ
5-1-1 LSTPPB021MRF0 M Latch head 1 AE
5-1-2 MSPRTA046WRE0 M Latch spring 1 AB
5- 2 FDORFB062MRT0 M Door panel 1 AW
5- 3 PSHEPB021MRE0 M Sealer film 1 AE
5- 4 GCOVHB038MRF0 M Choke cover 1 AG
5- 5 HPNL-B092MRE0 M Door screen [R-430DK & R-440DK] 1 AK
5- 5 HPNL-B093MRE0 M Door screen [R-430DW & R-440DW] 1 AM
5- 5 HPNL-B094MRE0 M Door screen [R-430DQ] 1 AM
MISCELLANEOUS
6- 1 FW-VZB125MRE0 M Stop switch harnnes 1 AF
6- 2 FW-VZB168MRE0 M Main wire harnnes [R-430DK/DW/DQ] 1 AU
6- 2 FW-VZB177MRE0 M Main wire harnnes [R-440DK/DW] 1 AU
6- 3 QW-QZB016MRE0 M High voltage wire A 1 AC
6- 4 FROLPB025MRK0 M Turntable support 1 AN
6- 5 NTNT-A095WRE0 M Turntable tray 1 AM
6- 6 TCAUAB037MRR0 M Monitor caution label 1 AA
6- 7 TCAUAB038MRR0 M DHHS/Screw caution label 1 AB
6- 8 TINSEB241MRR0 M Operation manual [R-430DK/DW/DQ] 1 AD
6- 8 TINSEB239MRR0 M Operation manual [R-440DK/DW] 1 AD
6- 9 TCADUB004MRP0 M RECIPE CARD 1 AC
6- 10 TLABBB007MRE0 M Cavity hole cover 1 AA
SCREWS,NUTS AND WASHERS
7- 1 LX-BZA041WRE0 M Special screw 1 AA
7- 2 LX-CZ0052WRE0 M Special screw 3 AA
7- 3 XHTSD40P12RV0 M Screw : 4mm x 12mm 1 AA
7- 4 LX-BZ0081YBE0 M Special screw 4 AA
7- 5 XOTSD40P12000 M Screw : 4mm x 12mm 8 AA
7- 6 XCBSD30P08000 M Screw : 3mm x 8mm 2 AA
7- 7 LX-CZA038WRE0 M Special screw 2 AA
7- 8 XHTSD40P08RV0 M Screw : 4mm x 8mm 3 AA
7- 9 LX-CZA070WRE0 M Special screw (Torx tamper proof screw) 2 AB
7- 10 XCPSD30P08000 M Screw : 3mm x 8mm 2 AA
