Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
∆
∆
*
∆
∆
∆
R31 VRD-B12EF471J Resistor 470 ohm 1/4W 1 AA
R40 VRD-B12EF101J Resistor 100 ohm 1/4W 1 AA
R41 VRD-B12EF512J Resistor 5.1k ohm 1/4W 1 AA
R60-71 VRD-B12EF332J Resistor 3.3k ohm 1/4W 12 AA
R80 RR-DZA089DRE0 Resistor array (RGLD4X104J) 1 AB
R100 VRD-B12EF105J Resistor 1M ohm 1/4W 1 AA
RY1 RRLY-A080DRE0 Relay (OJ-SH-124LM) 1 AG
RY2 RRLY-A076DRE0 Relay (OMIF-S-124LM) 1 AK
SP20 RALM-A014DRE0 Buzzer (PKM22EPT-CA) 1 AG
T1 RTRNPA064DRE0 Transformer 1 AS
VRS1 RH-VZA010DRE0 Varistor (TNR15G471K) 1 AE
ZD1 VHEHZ6A3///-1 Zener diode (HZ6A-3) 1 AC
ZD2 VHEHZ5C2///-1 Zener diode (HZ5C-2) 1 AA
ZD3 VHEHZ5A2///-1 Zener diode (HZ5A-2) 1 AA
3- 2 FPNLCB101WRK0 Control panel frame with key unit 1 BA
3- 2-1 FUNTKA611WRE0 Key unit 1 AY
3- 3 JBTN-A817WRF0 Open button 1 AK
3- 4 MSPRCA050WRE0 Open button spring 1 AB
3- 5 XEPSD30P10XS0 Screw : Control unit mounting 3 AA
OVEN PARTS
4- 1 LBNDKA038WRP0 Capacitor holder 1 AH
4- 2 LSTPPA069WRF0 Cord anchorage (upper) 1 AE
4- 3 LSTPPA070WRF0 Cord anchorage (lower) 1 AD
4- 4 FDAI-A150WRY0 Bottom plate 1 AY
4- 5 PDUC-A406WRF0 Air duct 1 AK
4- 6 PHOK-A076WRF0 Latch hook 1 AQ
4- 7 PCUSUA237WRP0 Waterproof cushion 1 AF
4- 8 PCUSUA236WRP0 Partition cushion 1 AF
4- 9 FOVN-A210WRT0 Oven cavity 1 BK
4-10 PCUSUA368WRP0 Cushion 1 AK
4-11 MLEVPA166WRF0 Latch lever 1 AE
4-12 FROLPA047WRK0 Roller stay 1 AW
4-13 NTNT-A036WRE0 Turntable 1 AX
4-14 GFTA-A008WRW0 Oven lamp access cover 1 AF
4-15 NCPL-A015WRF0 Turntable coupling 1 AD
4-16 PSPA-A084WRE0 Foot washer 1 AB
4-17 PCOVPA212WRE0 Waveguide cover 1 AF
4-18 PCUSUA157WRP0 Cushion 1 AC
4-19 PCUSUA300WRP0 Cushion 1 AH
4-20 PPACGA096WRE0 O-ring 1 AG
4-21 PFILWA041WRE0 Oven lamp filter 1 AA
4-23 PGIDHA044WRP0 Magnetron air guide 1 AM
4-24 LANGQA167WRM0 Earth angle (for New Zealand) 1 AB
4-25 LANGQA288WRP0 Noise filter angle (for New Zealand) 1 AC
4-26 PCUSGA322WRP0 Cushion 2 AF
4-27 PCUSGA321WRP0 Cushion 1 AH
4-28 PCUSUA278WRP0 MG cushion 1 AF
4-29 PCUSGA339WRP0 Trans. cushion 2 AG
4-30 NFANJA020WRE0 Fan blade 1 AG
4-31 PDUC-A468WRF0 Fan duct 1 AR
DOOR PARTS
5 CDORFA664WRK0 Door assembly, complete. 1 BG
5- 1 FDORFA229WRT0 Door panel 1 BG
5- 2 GCOVHA228WRF0 Choke cover 1 AH
5- 3 LSTPPA090WRF0 Latch head 1 AF
5- 4 MSPRTA114WRE0 Spring 1 AD
5- 5 HPNL-A515WRE0 Door screen 1 AX
5- 6 PSHEPA336WRP0 Sealer film 1 AF
5- 7 GWAKPA238WRF0 Door frame 1 AX
MISCELLANEOUS
6- 1 TCADCA543WRR0 Cook book 1 AZ
6- 2 TINS-A456WRR0 Instruction book 1 AK
6- 3 TCAUHA185WRR0 Microwave caution (for New Zealand) 1 AG
6- 4 PTUBUA004WRE0 Tube 220 1 AK
6- 5 QW-QZA141WRE0 High voltage wire A 1 AH
6- 6 TCAUHA055WRR0 Caution label 1 AF
6- 7 PTUBUA003WRE0 Tube 110 1 AF
6- 8 FW-VZB137WRE0 Main wire harness (for Australia) 1 AY
6- 8 FW-VZB138WRE0 Main wire harness (for New Zealand) 1 AY
