Sharp R-530EK - Page 40

38
R-530EK
R-530EW
∆
∆
∆
∆
*
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
4- 6 NFANPB006MRE0 M Fan blade 1 AC
4- 7 PDUC-B088MRF0 M Fan duct 1 AC
4- 8 ------------- M Oven cavity (Not a replaceable part) 1 --
4- 9 PCOVPB085MRP0 M Waveguide cover 1 AV
4-10 PPACGB014MRF0 M Turntable motor packing 1 AA
4-11 PDUC-B106MRP0 M Sensor duct 1 AG
4-12 PCUSU0464MRE0 M Cushion 1 AC
4-13 PCUSGB037MRP0 M Cushion 1 AA
DOOR PARTS
5- 1 GWAKPB129MRR0 M Door frame [R-530EK] 1 AN
5- 1 GWAKPB130MRR0 M Door frame [R-530EW] 1 AN
5- 2 LSTPPB021MRF0 M Latch head 1 AE
5- 3 MSPRTA046WRE0 M Latch spring 1 AB
5 -4 FDORFB049MRT0 M Door panel 1 AX
5- 5 LSTPPB036MRF0 M Door glass stopper 1 AC
5- 6 PSHEPB016MRE0 M Sealer film 1 AD
5- 7 PGLSPB024MRE0 M Door glass [R-530EK] 1 AQ
5- 7 PGLSPB025MRE0 M Door glass [R-530EW] 1 AQ
5- 8 GCOVHB039MRF0 M Choke cover 1 AG
5- 9 XEPSD30P06XS0 M screw; 3mm x 6mm 1 AA
MISCELLANEOUS
6- 1 FW-VZB125MRE0 M Stop switch harness 1 AF
6- 2 FW-VZB168MRE0 M Main wire harness 1 AU
6- 3 TLABBB007MRE0 M Cavity hole cover 1 AA
6- 4 FROLPB025MRK0 M Turntable support 1 AN
6- 5 NTNT-A099WRE0 M Turntable tray 1 AT
6- 6 TCAUAB037MRR0 M Monitor caution label 1 AA
6- 7 TCAUAB038MRR0 M DHHS/Screw caution label 1 AB
6- 8 TINSEB267MRR0 M Operation manual 1 AD
6- 9 QW-QZB016MRE0 M High voltage wire A 1 AD
6-10 TCADUB006MRR0 M Recipe card 1 AC
6-11 TLAB-B040MRR0 M Menu label 1 AD
SCREWS,NUTS AND WASHERS
7- 1 LX-BZA041WRE0 M Special screw 5 AA
7- 2 LX-CZ0052WRE0 M Special screw 3 AA
7- 3 XHTSD40P12RV0 M Screw : 4mm x 12mm 1 AA
7- 4 LX-CZA070WRE0 M Special screw (Torx tamper proof screw) 2 AB
7- 5 XOTSD40P12000 M Screw : 4mm x 12mm 11 AA
7- 6 XCBSD30P08000 M Screw : 3mm x 8mm 4 AA
7- 7 LX-CZA038WRE0 M Special screw 2 AA
7- 8 XHTSD40P08RV0 M Screw : 4mm x 8mm 3 AA
7- 9 XOTSF40P12000 M Screw : 4mm x 12mm [R-530EK] 4 AA
7- 9 XOTSE40P12000 M Screw : 4mm x 12mm [R-530EW] 4 AA
HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the following information.
1. MODEL NUMBER
2. REF. NO.
3. PART NO.
4. DESCRIPTION
Order Parts from the authorized SHARP parts Distributor for your area.
Defective parts requiring return should be returned as indicated in the Service Policy.
∆
