REF. NO. PART NO. DESCRIPTION Q'TY CODE
4-25 PCUSUA558WRPZ Cushion 1 AC
4-26 PDUC-A751WRTZ Exhaust duct 1 AP
4-27 LANGFA200WRPZ Support angle 1 AD
4-28 PCUSUA375WRP0 Cushion 1 AH
4-29 PCUSGA247WRP0 Cushion 1 AA
DOOR PARTS
5- 1 FDORFA343WRTZ Door panel 1 AS
5- 2 PSHEPA735WREZ Sealer film 1 AG
5- 3 FPNL-A040WRKZ Door screen assembly [R-610DK] 1 BF
5- 3 FPNL-A041WRKZ Door screen assembly [R-610DW] 1 BF
5- 3 FPNL-A040WRKZ Door screen assembly [R-610DS] 1 BF
5-3-1 PSHEPA736WREZ Key sheet [R-610DK] 1 AY
5-3-1 PSHEPA737WREZ Key sheet [R-610DW] 1 AY
5-3-1 PSHEPA736WREZ Key sheet [R-610DS] 1 AY
5- 4 GWAKPA736WRFZ Door frame [R-610DK] 1 AR
5- 4 GWAKPA737WRFZ Door frame [R-610DW] 1 AV
5- 4 GWAKPA738WRTZ Door frame [R-610DS] 1 AR
5- 5 JHNDPA188WRTZ Handle [R-610DK] 1 AP
5- 5 JHNDPA188WRTZ Handle [R-610DW] 1 AP
5- 5 JHNDPA186WRMZ Handle [R-610DS] 1 AP
5- 6 LANGKA941WRPZ Handle mounting angle 1 AR
5- 7 LSTPPA193WRFZ Latch head 1 AE
5- 8 MSPRTA187WRE0 Latch spring 1 AC
5- 9 LHLD-A225WRFZ LCD holder 1 AD
5-10 PCOVPA367WRWZ PWB cover 1 AD
5-11 LX-EZA059WREZ Special screw 2 AD
5-12 XCPSD40P08000 Screw : 4mm x 8mm 4 AA
5-13 XEPSD30P08XS0 Screw : 3mm x 8mm 4 AA
5-14 PCUSGA545WRPZ Cushion 1 AC
5-15 PCUSUA559WRPZ Cushion 1 AC
5-16 PCUSUA445WRP0 Cushion 1 AE
5-17 PSHEPA588WRE0 LED sheet 1 AE
5-18 XEPSD40P16000 Screw : 4mm x 16mm 2 AA
5-19 FW-VZA264DREZ 8-pin wire harness 1 AN
5-20 DPWBFC067WRKZ CPU unit 1 BA
5-21 XCPSD40P06000 Screw : 4mm x 6mm 2 AA
MISCELLANEOUS
6- 1 FROLPA095WRKZ Turntable support 1 AP
6- 2 NTNT-A099WRE0 Turntable tray 1 AX
6- 3 FW-VZB789WREZ Main wire harness 1 AS
6- 4 QW-QZA150WRE0 High voltage wire B 1 AF
6- 5 PZET-A012WRE0 Terminal insulator 1 AB
6- 6 TCAUAA156WRR0 User caution label 1 AF
6- 7 TCAUAA166WRR0 DHHS caution label 1 AC
6- 8 TCAUAA254WRR0 Monitor caution label 1 AC
6- 9 TCAUAA255WRR0 Screw caution 1 AC
6-10 TINSEA845WRRZ Instruction book 1 AD
6-11 FW-VZB801WREZ Switch harness 1 AF
6-12 FW-VZB802WREZ T.T. motor harness 1 AF
SCREWS,NUTS AND WASHERS
7- 1 XHPSD40P08K00 Screw : 4mm x 8mm 3 AA
7- 2 XBPSD40P08K00 Screw : 4mm x 8mm 2 AA
7- 3 XOTSD40P08000 Screw : 4mm x 8mm 18 AA
7- 4 LX-EZA057WREZ Special screw 4 AC
7- 5 XCPSD40P08000 Screw : 4mm x 8mm 1 AA
7- 6 XHPSD30P08XS0 Screw : 3mm x 8mm 2 AB
7- 7 XHTSD40P08RV0 Screw : 4mm x 8mm 1 AA
7- 8 LX-CZA070WRE0 Special screw (Torx tamper proof screw) 2 AC
7- 9 LX-CZ0052WRE0 Special screw 2 AA
7-10 XHPSD30P06000 Screw : 3mm x 6mm 1 AA
7-11 XHTSD40P08000 Screw : 4mm x 8mm 11 AA
7-12 XHTSD40P12RV0 Screw : 4mm x 12mm 1 AA
7-13 XOTSD40P12RV0 Screw : 4mm x 12mm 3 AA
7-14 XOTSF40P08000 Screw : 4mm x 8mm [R-610DK] 2 AA
7-14 XOTSE40P08000 Screw : 4mm x 8mm [R-610DW] 2 AA
7-14 XOTSE40P08000 Screw : 4mm x 8mm [R-610DS] 2 AA
7-15 LX-CZA079WREZ Special screw 1 AC
7-16 XOTSD40P10000 Screw : 4mm x 10mm 1 AA
7-17 LX-EZA060WREZ Special screw 4 AA
7-18 LX-CZA073WREZ Special screw 1 AC
