33-40 P27-P20 OUT Terminal not used.
41 P17 OUT Key strobe signal.
Signal applied to touch-key section. A pulse signal is input to P41, P43, P44 and P45
terminal while one of G8 line keys on key matrix is touched.
42 P16 OUT
Key strobe signal.
Signal applied to touch-key section. A pulse signal is input to P41, P43, P44 and P45
terminal while one of G7 line keys on key matrix is touched.
43 P15 OUT
Key strobe signal.
Signal applied to touch-key section. A pulse signal is input to P41, P43, P44 and P45
terminal while one of G6 line keys on key matrix is touched.
44 P14 OUT Key strobe signal.
Signal applied to touch-key section. A pulse signal is input to P41, P43, P44 and P45
terminal while one of G5 line keys on key matrix is touched.
45 P13 OUT Key strobe signal.
Signal applied to touch-key section. A pulse signal is input to P41, P43, P44 and P45
terminal while one of G4 line keys on key matrix is touched.
46 P12 OUT Key strobe signal.
Signal applied to touch-key section. A pulse signal is input to P41, P43, P44 and P45
terminal while one of G3 line keys on key matrix is touched.
47 P11 OUT Key strobe signal.
Signal applied to touch-key section. A pulse signal is input to P41, P43, P44 and P45
terminal while one of G2 line keys on key matrix is touched.
48 P10 OUT Key strobe signal.
Signal applied to touch-key section. A pulse signal is input to P41, P43, P44 and P45
terminal while one of G1 line keys on key matrix is touched.
49-50 P09-P08 OUT Terminal not used.
51-72 SEG21-SEG0 OUT Segment data signal.
Connected to LCD.
The relation between signals are as follows:
LSI signal (Pin No.) LCD (Pin No.) LSI signal (Pin No.) LCD (Pin No.)
SEG 21 (51) .................................. SEG3 SEG 10 (62) ...............................SEG14
SEG 20 (52) .................................. SEG2 SEG 9 (63) ...............................SEG13
SEG 19 (53) .................................. SEG1 SEG 8 (64) ...............................SEG12
SEG 18 (54) ................................ SEG22 SEG 7 (65) ...............................SEG11
SEG 17 (55) ................................ SEG21 SEG 6 (66) ...............................SEG10
SEG 16 (56) ................................ SEG20 SEG 5 (67) .................................SEG9
SEG 15 (57) ................................ SEG19 SEG 4 (68) .................................SEG8
SEG 14 (58) ................................ SEG18 SEG 3 (69) .................................SEG7
SEG 13 (59) ................................ SEG17 SEG 2 (70) .................................SEG6
SEG 12 (60) ................................ SEG16 SEG 1 (71) .................................SEG5
SEG 11 (61) ................................ SEG15 SEG 0 (72) .................................SEG4
73/74 VCC/VREF IN Connected to GND.
75 AVSS IN Connected to VC.
76 COM3 OUT Terminal not used.
77 COM2 OUT Common data signal: COM1.
Connected to LCD signal COM1.
78 COM1 OUT Common data signal: COM2.
Connected to LCD signal COM2.
79 COM0 OUT Common data signal: COM3.
Connected to LCD signal COM3.
80 VL3 IN Power source voltage input terminal.
Standard voltage for LCD.
