Sharp R-630DK Service Manual

38
R-630DK
R-630DW
R-630DS
∆
∆
∆
∆
∆
∆
∆
*
REF. NO. PART NO. DESCRIPTION Q'TY CODE
4-10 PPACGA084WRF0 TTM packing 1 AE
4-11 LANG-A081WRWZ Separate angle B 1 AD
4-12 ************* Oven cavity (Not a replaceable part) 1--
4-13 GCOVHA419WRFZ Choke cover 1 AK
4-14 LANGQA526WRWZ Lamp angle 1 AC
4-15 LANG-A077WRPZ Magnetron thermal cut-out angle 1 AC
4-16 PCOVPA361WREZ Waveguide cover 1 AD
4-17 PCUSGA057WRP0 Cushion 1 AA
4-18 PCUSUA557WRPZ Cushion 1 AC
4-19 PCUSUA556WRPZ Cushion 1 AC
4-20 PCUSUA126WRE0 Cushion 1 AC
4-21 PPACGA177WREZ Cushion 1 AC
4-22 PCUSUA560WRPZ Cushion 2 AB
4-23 PCUSUA376WRP0 Cushion 1 AF
4-24 PCUSGA548WRPZ Cushion 1 AK
4-25 PCUSUA558WRPZ Cushion 1 AC
4-26 PDUC-A761WRTZ Exhaust duct 1 AL
4-27 LANGFA200WRPZ Support angle 1 AD
4-28 PCUSUA375WRP0 Cushion 1 AH
4-29 PCUSGA247WRP0 Cushion 1 AA
4-30 PCUSGA057WRP0 Cushion 1 AA
DOOR PARTS
5- 1 FDORFA343WRTZ Door panel 1 AS
5- 2 PSHEPA735WREZ Sealer film 1 AG
5- 3 FPNL-A042WRKZ Door screen assembly [R-630DK] 1 BH
5- 3 FPNL-A043WRKZ Door screen assembly [R-630DW] 1 BG
5- 3 FPNL-A042WRKZ Door screen assembly [R-630DS] 1 BH
5-3-1 PSHEPA741WREZ Key sheet [R-630DK] 1 BA
5-3-1 PSHEPA742WREZ Key sheet [R-630DW] 1 BA
5-3-1 PSHEPA741WREZ Key sheet [R-630DS] 1 BA
5- 4 GWAKPA736WRFZ Door frame [R-630DK] 1 AR
5- 4 GWAKPA737WRFZ Door frame [R-630DW] 1 AV
5- 4 GWAKPA738WRTZ Door frame [R-630DS] 1 AR
5- 5 JHNDPA188WRTZ Handle [R-630DK] 1 AP
5- 5 JHNDPA188WRTZ Handle [R-630DW] 1 AP
5- 5 JHNDPA186WRMZ Handle [R-630DS] 1 AP
5- 6 LANGKA941WRPZ Handle mounting angle 1 AR
5- 7 LSTPPA193WRFZ Latch head 1 AE
5- 8 MSPRTA187WRE0 Latch spring 1 AC
5- 9 LHLD-A226WRFZ LCD holder 1 AD
5-10 PCOVPA367WRWZ PWB cover 1 AD
5-11 LX-EZA059WREZ Special screw 2 AD
5-12 XCPSD40P08000 Screw : 4mm x 8mm 4 AA
5-13 XEPSD30P08XS0 Screw : 3mm x 8mm 4 AA
5-14 PCUSGA545WRPZ Cushion 1 AC
5-15 PCUSUA559WRPZ Cushion 1 AC
5-16 PCUSUA445WRP0 Cushion 1 AE
5-17 PSHEPA672WRE0 LED sheet 1 AK
5-18 XEPSD40P16000 Screw : 4mm x 16mm 2 AA
5-19 FW-VZA265DREZ 12-pin wire harness 1 AT
5-20 DPWBFC097WRKZ CPU unit 1 BH
5-21 XCPSD40P06000 Screw : 4mm x 6mm 2 AA
MISCELLANEOUS
6- 1 FROLPA095WRKZ Turntable support 1 AP
6- 2 NTNT-A099WRE0 Turntable tray 1 AX
6- 3 FW-VZB789WREZ Main wire harness 1 AS
6- 4 QW-QZA150WRE0 High voltage wire B 1 AF
6- 5 PZET-A012WRE0 Terminal insulator 1 AB
6- 6 TCAUAA156WRR0 User caution label 1 AF
6- 7 TCAUAA166WRR0 DHHS caution label 1 AC
6- 8 TCAUAA254WRR0 Monitor caution label 1 AC
6- 9 TCAUAA255WRR0 Screw caution 1 AC
6-10 TINSEA863WRRZ Instruction book 1 AE
6-11 FW-VZB801WREZ Switch harness 1 AF
6-12 FW-VZB802WREZ T.T. motor harness 1 AF
6-13 TLABMA646WRRZ Menu label 1 AC
6-14 TCADCA724WRRZ Recipe sheet 1 AD
SCREWS,NUTS AND WASHERS
7- 1 XHPSD40P08K00 Screw : 4mm x 8mm 3 AA
7- 2 XBPSD40P08K00 Screw : 4mm x 8mm 2 AA
∆
