R-630DK
R-630DW
R-630DS
*
*
*
∆
*
∆
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ELECTRIC PARTS
1- 1 FACCDA083WRE0 Power supply cord 1 AQ
1- 2 QFSHDA009WRE0 Fuse holder 1 AH
1- 3 QSW-MA137WRE0 2nd interlock switch / door sensing switch 2 AH
1- 4 FFS-BA023WRK0
Monitor fuse 20A and monitor switch (AM5160C53Y1) assembly
1AS
1- 5 RTHM-A116WRE0 Thermal cut-out 125 deg. C (MG) 1 AK
1- 6 FH-DZA097WRKZ High voltage rectifier assembly 1 AP
1- 7 RC-QZA211WRE0 High voltage capacitor 1 AV
1- 8 RMOTEA395WRZZ Fan motor 1 AW
1- 9 RTRN-A609WRZZ Power transformer 1 BK
1-10 QSOCLA021WRE0 Oven lamp socket 1 AH
1-11 RLMPTA068WRE0 Oven lamp 1 AG
1-11 RLMPTA030WRE0 Oven lamp (Interchangeable) 1 AE
1-12 RMOTDA229WRE0 Turntable motor 1 AQ
1-12 RMOTDA211WRE0 Turntable motor (Interchangeable) 1 AS
1-13 RTHM-A123WRZZ Thermal cut-out 125 deg. C (OVEN) 1 AK
1-14 RV-MZA310WRZZ Magnetron 1 BG
1-15 FDTCTA209WRKZ AH sensor 1 AU
CABINET PARTS
2- 1 FDAI-A215WRYZ Base plate 1 AY
2- 2 GLEGPA074WRE0 Foot 1 AC
2- 3 GLEGPA081WRFZ Leg 1 AC
2- 4 GCABUA773WRPZ Outer case cabinet [R-630DK] 1 BD
2- 4 GCABUA775WRPZ Outer case cabinet [R-630DW] 1 BD
2- 4 GCABUA777WRPZ Outer case cabinet [R-630DS] 1 BD
2- 5 GLEGPA080WRFZ Front leg [R-630DK] 1 AL
2- 5 GLEGPA082WRFZ Front leg [R-630DW] 1 AL
2- 5 GLEGPA080WRFZ Front leg [R-630DS] 1 AL
2- 6 PPACGA178WREZ Cushion 2 AD
POWER UNIT PARTS
3- 1 DPWBFC096WRUZ Power unit 1 BB
3- 1A QCNCMA446DRE0 2-pin connector (CN-A) 1 AC
3- 1B QCNCMA431DRE0 2-pin connector (CN-B) 1 AC
3- 1C QCNCMA463DRZZ 12-pin connector (CN-C) 1 AE
3- 1D QCNCMA237DRE0 3-pin connector (CN-F) 1 AD
C1 VCEAB31VW108M Capacitor 1000 uF 35V 1 AF
C2 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AA
C3 VCEAB31VW106M Capacitor 10 uF 35V 1 AA
C50-51 RC-KZA087DRE0 Capacitor 0.1 uF 50V 2 AA
D1 RSRCDA013DRE0 Diode (S1NB10) 1 AG
IC2 VHIBA4558//-6 IC (BA4558) 1 AK
Q1 VS2SB1238//-3 Transistor (2SB1238) 1 AA
R1 VRD-B12EF242J Resistor 2.4k ohm 1/4W 1 AA
R2 VRD-B12HF681J Resistor 680 ohm 1/2W 1 AA
R50 VRS-B13AA331J Resistor 330 ohm 1W 1 AA
R51 RR-DZA285DRZZ Resistor 3.32k ohm 1/4W 1 AC
R52 RR-DZA286DRZZ Resistor 3.57k ohm 1/4W 1 AC
R53 VRN-B12EK182F Resistor 1.8k ohm 1/4W 1 AA
R54 VRN-B12EK364F Resistor 360k ohm 1/4W 1 AA
RY1 RRLY-A076DRE0 Relay (OMIF-S-124LM) 1 AK
RY2 RRLY-A113DRE0 Relay (DU24D1-P(M)-R) 1 AM
SP1 RALM-A014DRE0 Buzzer (PKM22EPT) 1 AG
T1 RTRNPA111DRE0 Transformer 1 AP
VRS1 RH-VZA032DRE0 Varistor (10G471K) 1 AE
ZD1 VHEHZ161///-1 Zener diode (HZ16-1) 1 AA
OVEN PARTS
4- 1 PHOK-A118WRFZ Latch hook 1 AH
4- 2 LBNDKA099WRW0 Capacitor holder 1 AD
4- 3 LFLG-A028WREZ Bearing 1 AL
4- 4 FANGKA211WRWZ Fan case assembly 1 AP
4- 5 LANGRA055WRWZ Fan motor mounting angle 1 AE
4- 6 LANGRA056WRWZ Bearing holder 1 AF
4- 7 NFANJA046WREZ Closs flow fan 1 AG
4- 8 LANG-A069WRPZ Magnetron air guide A 1 AL
4- 9 LANG-A080WRWZ Magnetron air guide B 1 AC
