Ref No. Midea Part No. Part Name&Description Pcs/Set Remarks
A01 252100100616 COVER WAVE GUIDE 1 C17L T=0.35
A13 251502901591 BRKT THERMOSTAT 1 C17L SGCC T=0.5
A16 251502901931 BRACKET TERMAL CUTOUT(MAG) 1 C17L T=0.5 (MGT)
B01 261501408000 BASE PLATE 1 M20L T=0.5
B02
261302000401
LEG
2
C17L PP T30
B02
261302000401
LEG
2
C17L
PP
T30
B03 261502500500 BRKT HINGE *U 1 C17L SPCC T=2.0
Z01 261501500300 HOLDER H.V.C 1 A23L SGCC T=0.5
C01 261300264402 PANEL CONTROL 1 M20L Silver
C05 261820902665 DECO. MEMBRANE 1
C18
261400124800
PCB ASS
'
Y
1
EGXEEXU 01 K
C18
261400124800
PCB
ASS'Y
1
EGXEEXU
-
01
-
K
C26 261400209140 SWITCH CIRCUIT 1
C55 261515901200 SHIELD 1 SGCC T=0.5
D01 261500201000 ASS'Y DOOR FRAME 1 C17L SPCC T=0.5
D02 261300500903 LATCH 1 C17L
D03
252010000388
SPRING LATCH
1
D03
252010000388
SPRING
LATCH
1
D04 251502401215 ASS'Y BRKT HINGE *T 1 C17L SPCC T=1.5
D05 262200400004 BARRIER SCREEN *I 1 C17L PET
D06 262100402835 BARRIER SCREEN *O 1
D07 261300141002 PANEL DOOR 1 M20L Silver
lk
D08 251300600081 GASKET DOOR 1 C17L PP T30 Black
D16 261301806801 HOLDER HANDLE 1 C17L PV Black
D54 261356102801 COVER HANDLE 1 C17L PV Silver
E01 251200100068 MAGNETRON 1 2M219J 900W
E05 251200200298 H.V.TRANSFORMER 1
E06 251200701308 H.V.CAPACITOR 1 1.00uF 2100V
E07 251200900861 H.V.DIODE 1 12kV 350mA
E10 261400300036 FILTER NOISE 1 FES1E
REPLACEMENT PARTS LIST
NOTE:
When ordering replacement part(s), please use part number(s) shown in this part list.
Do not use description of the part.
F
R-642(IN)W
or Model:
MD-801EMR-1 WLC
BWL-800E-23A WB0226
