Sharp R-875 Service Manual

R-875/885 - 46
∆
∆
∆
∆
∆
∆
Note: The parts marked "∆" may cause undue microwave exposure. / The parts marked "*" are used in
voltage more than 250V. / "§" Mark: Spare parts delivery section
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
∆
∆
3- 7 HPNLCB036URR0 U Control panel [R-875(B)] 1 AQ
3- 7 HPNLCK016URR0 U Control panel [R-875(K)] 1 AQ
3- 7 HPNLCW075URR0 U Control panel [R-875(W)] 1 AQ
3- 8 JBTN-O016URF0 U Express pizza button 1 AE
3- 9 JBTN-A102URT0 U Auto cook button [R-885(AL)] 1 AP
3- 9 JBTN-B020URF0 U Auto cook button [R-875(B)] 1 AD
3- 9 JBTN-K034URF0 U Auto cook button [R-875(K)] 1 AD
3- 9 JBTN-W031URF0 U Auto cook button [R-875(W)] 1 AD
3- 10 JBTN-A103URT0 U Stop/Watt button [R-885(AL)] 1 AP
3- 10 JBTN-B021URF0 U Stop/Watt button [R-875(B)] 1 AD
3- 10 JBTN-K033URF0 U Stop/Watt button [R-875(K)] 1 AD
3- 10 JBTN-W032URF0 U Stop/Watt button [R-875(W)] 1 AD
3- 11 JBTN-A104URT0 U More/Less button [R-875(W)[R-885(AL)] 1 AW
3- 11 JBTN-K035URF0 U More/Less button [R-875(B/K)] 1 AD
3- 12 JKNBKA042URT0 U Vari knob [R-885(AL)] 1 AE
3- 12 JKNBKB012URF0 U Vari knob [R-875(B)] 1 AE
3- 12 JKNBKK012URF0 U Vari knob [R-875(K)] 1 AE
3- 12 JKNBKW013URF0 U Vari knob [R-875(W)] 1 AE
3- 13 JKNBKA043URT0 U Timer knob [R-885(AL)] 1 AE
3- 13 JKNBKB013URF0 U Timer knob [R-875(B)] 1 AE
3- 13 JKNBKK013URF0 U Timer knob [R-875(K)] 1 AE
3- 13 JKNBKW014URF0 U Timer knob [R-875(W)] 1 AE
3- 14 MSPR-A002URE0 U Spring 1 AB
3- 15 XEPSD30P10XS0 U Screw : 3mm x 10mm 12 AA
OVEN PARTS
4- 1 DOVN-A023URK0 U Oven cavity 1 BG
4- 2 LBNDKA107WRP1 U Capacitor holder 1 AD
4- 3 FDUC-A003URY0 U Air duct assembly 1 AL
4- 4 LANGQA005URP0 U Air separate angle B 1 AC
4- 5 PDUC-A636WRP1 U Air guide duct 1 AM
4- 6 PFILWA001URP0 U Lamp filter 1 AB
4- 7 PHOK-A002URF1 U Latch hook 1 AH
4- 8 LANGQA014URP0 U Turntable motor angle 1 AE
4- 9 PCUSUA019URE0 U Cushion 1 AA
4-10 FANGTA003URY0 U Turntable motor shaft assembly 1 AL
4-11 PPACGA002URE0 U Seal packing 1 AB
4-12 NFANJA038WRE0 U Fan blade 1 AF
4-13 PDUC-A637WRF2 U Fan duct 1 AL
4-14 NFANMA002URP0 U Cooling fan 1 AF
4-15 GCOVHA001URP1 U Bottom heater cover 1 AM
4-16 LANGFA155WRP7 U Chassis support 1 AF
4-17 PPACGA001URE0 U Heater packing 1 AD
4-18 LANGQA008URP0 U Grill heater angle 2 AD
4-19 NFANMA001URP0 U Convection fan 1 AD
4-20 PSPAGA001WRE0 U Vibration proof cushion 1 AA
4-21 PCUSUA006URE0 U Air cushion B 1 AA
4-22 PCOVQA002URP0 U Heater cover 1 AD
4-23 PCOVPA308WRE1 U Waveguide cover 1 AE
4-24 PCUSUA015URE0 U Back plate cushion 1 AB
4-25 PPIP-A001UR10 U Pipe 1 AE
4-26 PCOVQA001URP0 U Rear heat cover 1 AP
4-27 PDUC-A606WRF1 U Air intake duct 1 AK
4-28 PDUC-A008URP0 U Exhaust duct 1 AK
4-29 PSKR-A308WRF0 U Rear barrier 1 AH
4-30 PDUC-A003URP0 U Convection duct 1 AL
4-31 PCUSUA012URE0 U Cushion 1 AB
4-32 LANGQA004URP0 U Convection air angle 2 AN
DOOR PARTS
5- 1 DDORFA766WRK0 U Door panel assembly 1 BE
5- 2 GWAKPB016URR0 U Door frame [R-875(B)] 1 AU
5- 2 GWAKPK011URR0 U Door frame [R-875(K)] 1 AU
5- 2 GWAKPW041URR0 U Door frame [R-875(W)] 1 AU
5- 2 GWAKPA103URR0 U Door frame [R-885(AL)] 1 AU
5- 3 LSTPPA017URF0 U Latch head 1 AG
5- 4 LHLD-A012URF0 U Glass holder [R-875(W)] [R-885(AL)] 1 AB
5- 4 LHLD-A013URF0 U Glass holder [R-875(B)] [R-875(K)] 1 AC
5- 5 MSPRTA197WREZ U Latch spring 1 AC
5- 6 PGLSPA027URE0 U Front door glass 1 AN
5- 7 JHNDPB001URF0 U Door handle A [R-875(B)] 1 AE
5- 7 JHNDPK005URF0 U Door handle A [R-875(K)] 1 AE
5- 7 JHNDPW002URF0 U Door handle A [R-875(W)] 1 AK
