Sharp R-939(BK) User Manual

R939(W)
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] OVEN PARTS
ELECTRIC PARTS
!
C RC-QZA219WRE1 AS High voltage capacitor
CH RHET-A269WRZ1 AY Convection heating element
CM RMOTEA415WRZ1 BB Convection motor
DM RMOTDA269WRZ1 AP Damper motor
F1 QFS-BA012WRZZ AG Fuse 20A
FM RMOTEA002URE2 AV Fan motor
GH RHET-A231WRZ1 AU Grill heating element
!
*
MG RV-MZA264WRE1 BG Magnetron
OL RLMPTA066WRE1 AP Oven lamp
SW1 QSW-MA146WRZ1 AM Monitored latch switch
SW2 QSW-MA147WRZ1 AM Stop switch
SW3 QSW-MA146WRZ1 AM Monitor switch
SW4 QSW-MA147WRZ1 AM Damper switch
!
T RTRN-A016URE2 BL High voltage transformer
TC1 RTHM-A098WRE0 AK Thermal cut-out 125°C (MG)
TC2 RTHM-A109WRE0 AM Thermal cut-out 170°C (GRILL)
TC3 RTHM-A109WRE0 AM Thermal cut-out 170°C (CONV.)
TTM RMOTDA267WRZ1 AP Turntable motor
!
1-1 FH-DZA035WRE1 AS High voltage rectifier assembly
1-2 QACCVA004URE3 AT Power supply cord
1-3 FPWBFA309WRE4 AT Noise filter (F2: Fuse F8A)
1-4 RTRN-A529WRE1 AW TC transformer
1-5 FH-HZA075WRE0 AS Thermistor
CABINET PARTS
2-1 GCABDA005URP1 BC Back plate
2-2 GCABUB051WRPZ BM Outer case cabinet [R-939(W)]
2-2 GCABUB052WRPZ BN Outer case cabinet [R-939(BK)] [R-939(IN)]
2-3 GLEGPA057WRE2 AF Foot
2-4 GDAI-A003URP3 BA Base plate
OVEN PARTS
4-1 PCUSUA312WRP0 AC Cushion
4-2 PCUSUA050URE0 AB Cushion
4-3 LANGFA002URP0 AL Cavity support angle
* 4-4 DOVN-A024URK0 BU Oven cavity
4-5 MCAMPA001URF1 AF Damper cam
4-6 LANGTA009URP2 AG Damper angle
4-7 FFTA-A001URK0 AM Damper assembly
4-9 PDUC-A011URF1 AQ Air intake duct
4-10 PDUC-A014URP0 AH Exhaust duct
4-11 PSKR-A010URP0 AF Partition plate B
4-12 PDUC-A012URP0 AL Air duct
4-13 LANGQA017URP0 AF Grill heater angle
4-14 QTANNA001URP0 AC Earth plate
4-15 PREFHA001URP0 AS Grill reflector
4-16 LANG-A054WRP1 AK Convection heater angle
4-17 LANGQA308WRP1 AK Convection motor angle
4-18 NFANMA003URP0 AF Cooling fan
4-19 PDUC-A042URP0 AG Convection duct
4-20 PPIPFA005UR10 AK Pipe
4-21 PSKR-A013URP0 AG Air separate angle A
4-22 PSKR-A014URP0 AF Air separate angle B
4-23 PSKR-A015URP0 AF Air separate angle C
4-24 PSKR-A016URP0 AF
Air separate angle D
4-25 PSLDHA005URP0 AQ Rear heat cover
4-26 LANGQA018URP1 AM Convection heater angle A
4-27 PFPF-A002URE1 AL Heat insulating material
4-28 PSKR-A012URP0 AG Air separate angle E
4-29 PSKR-A308WRF1 AL Rear barrier
4-30 NFANMA004URP0 AG Convection fan
* 4-31 PHOK-A002URF1 AT Latch hook
4-32 PDUC-A016URF1 AQ Fan duct
4-33 NFANJA038WRE0 AG Fan blade
4-34 GCOVHA002URP0 AG Bottom heater cover
4-35 LANGFA001URP1 AL Chassis support
4-36 NCPL-A040WRE2 AL Coupling
4-37 PCOVPA309WRE0 AF Waveguide cover
4-38 PFPF-A003URE2 AM Heat insulating material
4-39 PFILWA001URP0 AG Lamp filter
4-40 PPACGA101WRE0 AF O-ring
4-41 PSLDHA002URP3 AS Heater cover right
4-42 PSPAGA001WRE0 AB Vibration proof cushion
4-43 LBNDKA111WRP1 AG Capacitor holder
MISCELLANEOUS
6-1 FROLPA060WRK0 AW Roller stay
6-2 NTNT-A040WRE0 AZ Turntable tray
6-10 LHLDKA008WRF1 AF P-clip
SCREWS, NUTS AND WASHERS
7-1 XHPS740P08K00 AB Screw: 4mm x 8mm
7-2 LX-EZA042WRE0 AB Special screw
7-3 XCBWW30P06000 AA Screw: 3mm x 6mm
7-4 XNEUW40-32000 AA Nut: 4mm x 3.2mm
7-5 XRES740-06000 AB Ring
