Sharp SJ-43L-A2G - Electrical Accessories Layout Diagram

11
SJ-43L-A2
SJ-47L-A2
Figure W-2. Electric Accessories Layout
Cabinet ass'y
E.V. cover ass'y
Lead EV-cover ass'y
Fan motor
F-thermostat
Def thermo. ass'y
Fuse ass'y
FM
Def. heater ass'y
Door switch
2 (PUSH OPEN)
3 (PUSH CLOSE)
4 (PUSH OPEN)
1 (NEUTRAL)
1
2
1
2
1
2
1
2
1
2
3
4
1
2
3
4
1
2
3
4
1
L
E
N
1
5
2
6
3
7
4
8
1
5
2
6
3
7
4
8
GY-1
OR-1
R-1
BR-1
Y- 1
W-1
BL-1
BL-2
BR-2
SB-1
(SB-1)
BK-1
(W-1)
Y- 2
(OR-1)
R lamp box ass'y
Lamp 15W
Lamp socket
L
Terminal box
TM
Defrost timer
(Y-1)
(Y-2)
(R-1)
(BK-1)
GY-2
Terminal block
Protector
Compressor
C
M
A
Starting
relay
Source cord
BROWN
BLUE
GRAY
EARTH
G
BR
OR
Y
R
P
BL
BK
SB
G-Y
W
: GRAY
: BROWN (live)
: ORANGE
: YELLOW
: RED
: PINK
: BLUE (neutral)
: BLACK
: SKY-BLUE
: GREEN-YELLOW (earth)
: WHITE
Running capacitor
