5
SJ-58L-A2
SJ-63L-A2
SJ-68L-A2/R2
LIST OF ELECTRICAL PARTS
ITEMS TYPE NAME RATING SPECIFICATIONS
Thermostat MM1-8123 125V 6A (At normal notch)
250V 3A ON/OFF : -19/-24˚C
Defrost thermostat US-602S 250V 8A Open/Close : 10/1˚C
Thermo. fuse SF70E 250V 10A Working temp. : 70˚C
F-fan motor 3R00044A 100V 50/60Hz Working with ø100 fan
110V 60Hz
R-fan motor 3R00122B 100V 50/60Hz Working with ø80 fan
127V 50/60Hz
(R-fan fuse) 123 250V 2A Cut OFF 130˚C
Defrost heater MM6-4199D 105V 150W With deodorizer
Door switch DSD-5 125V 0.5A 4 terminals push-button type
Damper thermostat MM1-6170 — Open/Close : 3.0/-2.0˚C
Defrost timer TMDFX04FB2 110-127V Integration type
50/60Hz Cycle time : 12/10 hours(50/60Hz)
Delay time : 4.8/4.0 min.(50/60Hz)
Lamp socket (F/R) — 250V 1A E-12(Hard plastic body type)
F-lamp — 110V 10W E-12
R-lamp — 110V 15W E-12
R-fan thermo.
R-fan thermo.
S101 125V 15A Open/ Close : 7/ 15 ˚C
ass'y
R-fan thermo.heater
RSS2 2W (1.2W 110V) 10kΩ
Compressor FGI85HAK 115V/60Hz Cooling capacity : 209kcal/h(60Hz)
Main coil : 1.78Ω
Aux. coil : 6.8Ω
(at 25˚C)
Starting relay RTH7M4R7MC1 — 4.7Ω 20% 180V
Overload relay(Protector) 4TM771RFBZZ — Open/ Close : 130/61˚C
+
Common
Main coil
Aux. coil
