5
ENGLISH
1
Keep adequate ventilation space around the
refrigerator.
• The gure shows the
minimum required
space for installing
the refrigerator. The
measurement condition
of power consumption
is conducted under
a different space
dimension.
• By keeping greater
space, the refrigerator may consume a less amount
of power consumption.
• If use the refrigerator in the smaller space
dimension than gured, it may cause temperature
rise in the unit, loud noise and failure.
• The space between the rear of the refrigerator and
the wall should be 60mm or more, and less than
75mm.
If the space is wider than 75mm, you may get
injured by touching compressor and its peripheral
parts which are extremely hot during the operation.
Overall space required in use
Installation
Free standing type
or more
60mm
or more
60mm
or more
1500 mm
2
Use the two front the adjustable feet to place the
refrigerator atly and rmly on the oor.
3
When right and left doors are not properly aligned,
adjust using the adjustable feet.
Adjustable foot
Note
• Place your refrigerator to access the plug.
• Keep your refrigerator out of direct sunlight and do not
place next to heat generating appliance.
• Do not place your refrigerator directly on the ground.
Insert suitable stand such as wooden board under the
refrigerator.
• When you insert the power plug with the door opened,
door alarm sounds but it is not abnormal. This sound
stops after closing the door.
Before using your refrigerator
Clean the inside parts with a cloth soaked in warm
water.
If soapy water is used, wipe it off thoroughly with water.
When the left door is
raised.
When the right door is
raised.
Lower the foot
at right side.
Lower the foot
at left side.
(Until the adjustable foot on the
other side is slightly off-ground.)
4
Remove the 4 screws of the lower part of the cabinet
and use these screws to set the foot cover. (The foot
cover is packed inside the refrigerator compartment.)
Screw
(4 screws)
Screw
Foot cover
(B700).indb 5 2016/01/26 13:36:10
