SJ-P58M/58M
SJ-P63M/63M
SJ-P68M/68M
SJ-P68M SJ-P68M SJ-P68M SJ-68M SJ-68M SJ-68M
-GY -SL -WH -GY -SL -WH
REF. NO. PART NO. DESCRIPTION Q'TY CODE
REPLACEMENT PARTS LIST (SJ-P68M-GY/SL/WH,SJ-68M-GY/SL/WH)
ELECTRIC PARTS
1-1 RTHM-A097CBEZ F-thermostat 111111 AX
1-2 RSTT-A138CBE0 Starting relay 111111 AV
1-3 QSWTDA047CBZZ Defrost timer 111111 AZ
1-4 PDMP-A052CBEZ Damper thermo 111111 AW
1-5 FTHM-A038CBKZ Defrost thermo.ass'y 111111 AM
1-6 RMOTRA046CBE0 Fan motor 111111 AZ
1-7 QSOCAA091CBZZ Lamp socket 111111 AN
1-8 RLMP-A012CBE0 Lamp 111111 AH
1-9 QACC-A156CBZZ Source cord 111111 AQ
1-10 QSW-PA090CBZA Door switch 111111 AS
1-11 RHOG-A124CBE0 Protector 111111 AX
1-17 FFS-TA055CBKZ Fuse ass'y 111111 AL
1-20 FW-VZA150CBZZ Lead ev-cover ass'y 111111 AK
1-21 FHETBA146CBEZ Def.heater ass'y 111111 AZ
1-22 FCNW-A726CBKZ Relay cord s ass'y 111111 AK
1-23 QCNW-A671CBE0 Reray wire rc 111111 AD
1-25 QTAN-A050CBZZ Terminal block 111111 AS
1-27 RMOTRA061CBEZ Fan motor 111111 AW
1-28 RLMP-A029CBEZ Lamp15w 111111 AH
1-29 QSOCAA072CBEZ Lamp socket 111111 AN
1-30 FTHM-A029CBKZ R fan thermo ass'y 111111 AQ
1-31 RC-EZA199CBZZ Running capacitor 111111 AT
1-33 QCNW-A886CBE0 Olr cord 111111 AE
1-34 QCNW-A968CBZZ Earth wire 111111 AC
1-45 FTRN-A014CBKZ Ionaizer-k 111--- AZ
1-46 QCNW-A999CBZZ Plasma harness 111--- AF
1-50 FPWB-A337CBKZ Main pwb 111--- BC
1-55 FPWB-A336CBKZ Panel pwb ass'y 111--- AT
MECHANICAL PARTS
2-2 JKNB-A036CBFC F-temp. control knob 111111 AC
2-7 FLEGPA077CBKZ Leg holder l ass'y 111111 AQ
2-7-1 FAJS-A013CBK0 Adjustable leg ass'y 222222 AE
2-7-2 LHLD-A533CBPZ Leg holder l 111111 AL
2-8 FLEGPA078CBKZ Leg holder r ass'y 111111 AQ
2-8-2 LHLD-A534CBPZ Leg holder r 111111 AP
2-10 PSPAVA083CBEA Upper hinge spacer 111111 AD
2-11 PSPAVA085CBEA Bottom hinge spacer 111111 AC
2-12 PSPAVA075CBEA Center hinge spacer 111111 AD
2-13 DHNG-A437CBMZ Upper hinge ass'y 111111 AE
2-14 DHNG-A442CBMZ Bottom hinge 111111 AE
2-15 DHNG-A438CBMZ Center hinge r ass'y 111111 AE
2-16 GCOV-A191CBFZ E.v cover 111111 AS
2-17 LCRA-A010CBE0 Fan clamp 222222 AD
2-19 LHLD-A389CBF0 Motor cushion 222222 AF
2-20 NFANPA020CBFA Propeller fan 100 111111 AE
2-21 PSEL-B845CBEZ E.v cover sealer a 111111 AC
2-22 PSEL-B846CBEZ E.v cover sealer b 111111 AC
2-23 PSEL-A415CBE0 E.v cover sealer c 111111 AC
2-24 LPLTMA653CBPZ Terminal cover 111111 AE
2-25 PCOV-A253CBFB F lamp cover 111111 AD
2-26 PCOV-A254CBFB R lamp cover 111111 AF
2-27 GCOVPA130CBRB R-cbox cover 111111 AS
2-28 HGRL-A184CBRB Fan louver 111111 AT
2-29 GCOV-A228CBFA Upper hinge cover -1--1- AE
2-29 GCOV-A228CBFB Upper hinge cover 1--1-- AE
2-29 GCOV-A228CBFF Upper hinge cover --1--1 AF
2-30 PCOV-A255CBFC Fan cover 222222 AE
2-31 JKNB-A033CBFC R-temp.control knob 111111 AC
2-32 HGRL-A215CBFA R deod.louver 111111 AC
2-33 HGRL-A216CBRA F deod.louver 111111 AE
2-34 PFIL-A047CBEZ Deodorizer 222222 AC
2-35 PSEL-C081CBEZ A-sealer ag4 222222 AA
2-36 PCAP-A006CBFW Screw cover --2--2 AB
2-36 PCAP-A006CBFX Screw cover 2--2-- AB
2-36 PCAP-A077CBFA Screw cover -2--2- AA
2-38 PGID-A156CBFZ R air guider a ---111 AG
2-38 PGID-A163CBFZ R air guider a 111--- AG
2-41 PSEL-B848CBEZ A-sealer thermo.cap 111111 AC
2-45 LPLTPA323CBMA Panel base 111--- AN
2-47 LHLD-A618CBFZ Plasma holder 111--- AE
2-48 PCOV-A284CBFZ Holder cover 111--- AB
2-49 LSTPPA108CBFA Chilled stopper 222222 AC
2-50 NFANPA019CBFA Propeller fan 80 111111 AM
