SJ-P58M/58M
SJ-P63M/63M
SJ-P68M/68M
COOLING UNIT
Figure C-1. Cooling unit
Hot pipe L
(Side condenser)
Hot pipe
(DP-condenser)
Hot pipe R
(Side condenser)
Evaporator
Suction pipe
Sub. condenser
Compressor
Capillary tube
Dryer
Back condenser
Mark: Refrigerant flow
Mark: Brazing portion
