6
SJ-V35L
SJ-V39L
LIST OF ELECTRICAL PARTS
ITEMS TYPE NAME RATING SPECIFICATIONS
Damper thermostat MM1-6129 Open : 0.5˚C , Close : -4˚C
Defrost thermostat US602S 250V,8A Open : 10˚C , Close : 1˚C
Timer ND0804M2PR 200-240V Integration type
50/ 60Hz Cycle time : 8h43m(50Hz)
Delay time : 4m50s(50Hz)
Thermo. fuse (defrost) SF70E 250V,10A Cut off temperature : 72˚C
Door switch PS100-01T 250V,0.5A 2 terminals type push-button
(Freezer compartment)
Door switch PS100-T 250V,0.5A 3 terminals type push-button
(
Refrigerator compartment
)
Fan motor 3R00044B 220/240V,50Hz
Lamp — 240V,10W E-12
Lamp socket — 250V,1A E-12 (Hard plastic body type)
F-thermostat MM1-8038 ON : -20˚C , OFF : -25˚C
Defrost heater MM1-4021 220/230/240V 378Ω with deodorizer
Compressor FL1568SZ 220/230/240V
50Hz Main : 13.3Ω Terminal shape
Aux : 25.6Ω
Cooling capacity 188W
Starting relay PETOSAT 300V 22Ω
Protector 2.0C36A1 — 130˚C / 60˚C
