10.Fix the Fl al sheet, and the Ev cover al.
Figure A-10
3. Installing of Evaporator
1. Install Evaporator as shown in the Figure A-1 in the reverse order of Figure A-2.
2.Correctthedefromedn.
NOTE:
1.WheninstallingEvaporator,takecarenottodeformsignicantlyandbreakthepipes.
2.TakecarenottodamagetheleadwiresandhurtyourselfbythenofEvaporator.
3. You shouldn’t touch Defrost heater with your bare hand. (You should wear pure gloves.)
4. You should wipe that with alcohol. When you touch Defrost heater with your bare hand.
Fl al sheet
3 Adjust to bottom line
Fl al sheet
1 Adjust to left end of Heater support
4 Adjust to projection of Food liner
projection
Ev cover al
2 Cover the screw
