PRECISION MACHINE TOOLS Ver 2 Maintenance Manual
Item Order Number Name Qty.
1 A0110000100 Column ( SV4328 ) 1
1 A0410000100 Column ( SV5128 ) 1
2 A0153000100 Ball screw ( SV4328 ) 1
2-1 A0453000100 Ball screw ( SV5128 ) 1
3 D0011060021 M10 safety washer 6
4 D0000060301 M10*30mm screw 6
5 D0000030201 M5*20mm screw 4
6 C0151000100 X axis left stopper 4
7 C0050000100 Oil seal 4
8 A0150000100 X & Y axes motor adapter 1
9 C0050000200 Bearing 6
10 A0150000700 Outside bearing retainer 2
11 A0153000200 Bearing cap 2
12 D0011050021 M8 safety washer 12
13 D0000050351 M8*35mm screw 12
14 A0153000300 Inside bearing retainer 1
15 C0050000300 Lock nut 2
16 D0011070021 M12 safety washer 18
17 C0088003300 Tapping pin with internal thread(1~48”) 4
18 D0000705501 M12*55mm screw 8
19 B0153000100 X & Y axes motor adapter cover 1
20 D0010030011 M5 washer 4
21 D0000030151 M5*15mm screw 4
22 A0152000200 Y axis bearing case 1
23 A0150000600 Inside bearing retainer 1
24 A0113000100 Weight balance bracket 1
25 D0010090051 M16 washer 1
26 D0000090451 M16*45mm screw 1
27 D0018170013 M36 hanging ring 2
28 D0000070451 M12*45mm screw 10
29 A0113000200 Weight balance support frame 1
30 D0000060201 M10*20mm screw 4
To Next Page
