PRECISION MACHINE TOOLS Ver 2 Maintenance Manual
Item Order Number Name Qty.
31 A0113000300 Sprocket shaft 4
32 C0088003400 Needle bearing 4
33 A0113000400 Sprocket wheel 4
34 A0113000500 Sprocket bolt 4
35 D0012110101 Nut 4
36 C0113000100 Sprocket 2
37 A0113000600 Weight balance case 1
38 A0113000700 Weight balance upper bearing socket 1
39 D0011040011 M6 Safety washer 6
40 D0000040251 M6*25mm screw 6
41 C0088003500 Linear bearing 2
42 C0088003600 Restrain ring 2
43 A0113000800 Weight balance under bearing socket 1
44 A0113000900 Weight balance guide 1
45 D0010070031 M12 washer 4
46 D0000070401 M12*40mm screw 4
47 B0153000200 Z direction cable chain bracket 1
48 D0010050011 M8 washer 12
49 D0000050201 M8*20mm screw 12
50 C0153001000 Z direction cable chain 1
51 D0010130031 M24 safety washer 10
52 D0000130901 M24*90mm screw 10
53 A0113001000 Weight balance guide plate 1
To Next Page
