139
PRECISION MACHINE TOOLS Ver 2 Maintenance Manual
Item Order Number Name Qty.
1 A0210000100 Column
1
2 A0253000200 Ball screw
1
3 D0011070301 M12 safety washer
5
4 D0000070301 M12*30mm screw
5
5 D0000040201 M6*20mm screw
14
6 C0253000300 stopper
1
7 C0062000119 Oil seal
4
8 D0011080051 M12 safety washer
10
9 A0250000100 X & Y axes motor adapter
1
10 C0050000400 TAC bearing
6
11 A0250000400 Bearing cap
2
12 D0011050021 M8 safety washer
12
13 D0000050301 M8*30mm screw
12
14 A0250000500 Inside bearing retainer
2
15 C0050000500 Lock nut
2
16 C0088003300 Tapping pin with internal thread(1~48”)
4
17 D0000080601 M14*60mm screw
10
18 B0270000300 X & Y axes motor adapter cover
1
19 D0010030011 M5 washer
8
20 D0000030151 M5*15mm screw
8
21 D0000040151 M6*15mm screw
20
22 C0253000400 Stopper
2
23 C0253000500 Z axis stopper base ( ball screw bottom side )
1
24 D0011040021 M6 safety washer
36
25 A0250000200 Axis bearing case
1
26 A0213000100 Counterweight balance support frame
2
27 D0011090001 M16 safety washer
8
28 D0000090501 M16*50mm screw
8
29 A0213000200 Sprocket bolt
4
30 D0012110101 Nut
4
