PRECISION MACHINE TOOLS Ver 2 Maintenance Manual
Item Order Number Name Qty.
31 C0213000100 Sprocket
2
32 B0213000100 Counterweight balance support frame cover
2
33 D0018210013 M48 Hanging ring
2
34 A0213000300 Sprocket shaft 4
35 C0088003400 Needle bearing 8
36 A0213000400 Sprocket wheel 4
37 B0213000200 Column back hole cap 2
38 A0213000500 Weight balance bracket 2
39 D0010060201 M10 washer 10
40 D0000060351 M10*35mm screw 10
41 C0088003600 Restrain ring 2
42 C0088003500 Linear bearing 2
43 D0000040251 Hex socket head screw 6
44 A0113000800 Counterweight bearing socket in under 1
45
A0213000600 Counterweight 1
46 A0113000700 Counterweight bearing socket in upper 1
47 A0213000700 Weight balance guide 1
48 D0000130901 M24*90mm screw 12
49 D0011130501 M24 safety washer 12
50 A0213000800 Counterweight bracket in under 1
