PRECISION MACHINE TOOLS Ver 2 Maintenance Manual
Item Order Number Name Qty.
1 A0120000100 Saddle base ( SV4328 ) 1
1-1 A0420000100 Saddle base ( SV5128 ) 1
2 A0151000100 Ball screw ( SV4328 ) 1
2-1 A0451000100 Ball screw ( SV5128 ) 1
3 D0011060021 M10 safety washer 6
4 D0000060301 M10*30mm screw 6
5 D0000030201 M5*20mm screw 4
6 C0151000100 X axis left stopper 4
7 C0050000100 Oil seal 4
8 A0150000100 X & Y axes motor adapter 1
9 C0050000200 Bearing 6
10 A0150000500 Outside bearing retainer 1
11 A0151000400 Bearing cap 2
12 D0011050021 M8 safety washer 16
13 D0000050351 M8*35mm screw 14
14 A0150000600 Inside bearing retainer 2
15 C0050000300 Lock nut 2
16 D0011070021 M12 safety washer 27
17 C0088003300 Tapping pin with internal thread(1~48”) 6
18 D0000070501 M12*50mm screw 10
19 B0151000100 X & Y axes motor adapter cover 1
20 D0010030011 M5 washer 4
21 D0000030151 M5*15mm screw 68
22 A0151000300 Axis bearing case 1
23 A0150000700 Outside bearing retainer 1
24 B0151000300 X direction cable chain bracket 1
25 D0010040011 M6 washer 9
