147
PRECISION MACHINE TOOLS Ver 2 Maintenance Manual
Item Order Number Name Qty.
26 D0000040151 M6*15mm screw 9
27 C0188000100 Cable chain 1
28 D0000030081 M4*8mm screw 4
29 A0130100100 X axis left front pressure plate 1
30 A0130100200 X axis right front pressure plate 1
31 D0004060401 Adjustable embedded bolt 14
32 A0130100300 X axis left rear pressure plate 1
33 A0130100400 X axis right rear pressure plate 1
34 D0000070551 M12*55mm screw 20
35 A0130100500 X axis embedded guide plate 4
36 A0001002000 O-ring 4
37 B0151000200 X direction cable chain bracket 1
38 A0151000400 X axis nut base 1
39 A0130100600 Table embedded plate 2
40 A0130000100 Table ( SV4328 ) 1
40-1 A0430000100 Table ( SV5128 ) 1
41 A0130100700 Adjustable spacer 2
42 D0000050301 M8*30mm screw 4
43 D0011040011 M6 safety washer 4
44 D0000040201 M6*20mm screw 4
45 C0151000200 X axis right front wiper 1
46 C0151000300 X axis right rear wiper 1
47 C0151000400 X axis left front wiper 1
48 C0151000500 X axis left rear wiper 1
49 B0170001000 Y direction cable chain 1
50 D0010050011 M8 washer 2
To Next Page
