PRECISION MACHINE TOOLS Ver 2 Maintenance Manual
Item Order Number Name Qty.
51 D0000050251 M8*25mm screw 2
52 C0152000100 Y axis left outside wiper 2
53 C0152000200 Y axis right rear wiper 1
54 C0152000300 Y axis left rear wiper 1
55 C0152000400 Y axis right outside wiper 2
56 B0170001100 Y axis support embedded plate 1
57 A0120100100 Embedded saddle plate 1
58 C0152000500 Y axis right front wiper 1
59 C0152000600 Y axis left front wiper 1
60 D0000080601 M14*60mm screw 10
61 D0010080021 M14 safety washer 10
62 A0120100200 Right saddle pressure plate 1
63 A0120100300 Left saddle pressure plate 1
64 A0120100400 Embedded saddle guide plate 2
65 C0062000111 O-ring 4
