Sharp UHL Series User Manual

EN-2
INDOOR UNIT
PART NAMES
1 Inlet (Air)
2 Open Panel
3 Air Filter
4 AUX Button
5 Receiver Window
6
7
8 Outlet (Air)
9 OPERATION Lamp (Green )
10 TIMER Lamp (orange
)
11 PLASMACLUSTER Lamp (blue
)
(For UHL models only)
9
1
2
3
4
5
6
7
8
11
10
9
10
OUTDOOR UNIT
12
13
14
15
12
13
14
15
12 Inlet (Air)
13 Refrigerant Pipe and Cable
14 Drainage Hose
15 Outlet (Air)
AU-A5UHL, AU-A5UDL, AU-A5UEY
AU-A7UHL, AU-A7UDL
AU-A9UHL, AU-A9UDL, AU-A9UEY
AU-A12UHL
UDL, UEY models
UHL models
