VC-GH61GM/SM,GH611GM
VC-GH60SM,GH600SM,GH601SM
VC-FH310GM/SM
ROM MAP
MODEL GH61GM GH611M FH310GM GH61SM FH310SM GH60SM GH600SM GH601SM
PAL SP 46 46 46 46 46 46 46 46
PAL LP 26 26 26 26 26 26 26 26
SECAM SP 07 07 07 07 07 07 07 07
SECAM LP 07 07 07 07 07 07 07 07
IC701 iXA044WJ iXA044WJ iXA044WJ iXA044WJ iXA044WJ iXA045WJ iXA045WJ iXA045WJ
JP39 A.DUB 0 0 0 0 0 0 0 0
JP38 NOT SLOW ATR 00000000
JP37 S.SIMPLE PB 11111000
JP36 NTPB 1 1 1 1 1 1 1 1
JP35 NTSC SKEW 00000000
JP34 HEAD 2 0 0 0 0 0 0 0 0
JP33 HEAD 1 1 1 1 1 1 1 1 1
JP32 HEAD 0 0 0 0 0 0 0 0 0
JP31 GAMMA 0 0 0 0 0 0 0 0
JP30 LOW PWR 5MIN 00000000
JP29 POSI84 1 1 1 1 1 1 1 1
JP28 R/C CODE 0 0 0 0 0 0 0 0
JP27 DNR 0 0 0 0 0 0 0 0
JP26 POST CODE 00000000
JP25 SAT CTL 0 0 0 0 0 0 0 0
JP24 AV LINK/16:9 00101000
JP23 Hi-Fi 1 1 1 1 1 1 1 1
JP22 SORT/CLOCK 11111000
JP21 DECODER 1 1 1 1 1 1 1 1
JP20 SURROUND 00000000
JP19 IGR 1 1 1 1 1 1 1 1
JP18 NICAM 0 0 0 1 1 1 0 1
JP17 G-CODE1 0 0 0 0 0 0 0 0
JP16 G-CODE0 1 1 1 1 1 0 0 0
JP15 EP 1 1 1 1 1 1 1 1
JP14 LP 0 0 0 0 0 0 0 0
JP13 F-AV 1 1 1 1 1 1 1 1
JP12 2 SCART 1 0 1 1 1 1 1 1
JP11 RF OUTPUT OFF 00000000
JP10 TUNER2 0 0 0 0 0 0 0 0
JP9 TUNER1 0 0 0 0 0 0 0 0
JP8 TUNER0 0 0 0 0 0 0 0 0
JP7 SYSTEM1 0 0 0 0 0 0 0 0
JP6 SYSREM0 0 0 0 0 0 0 0 0
JP5 380FF/REW 1 1 1 1 1 1 1 1
JP4 LOW POWER 00000000
JP3 OEM 0 0 0 0 0 0 0 0
JP2 VPS/PDC 1 1 1 1 1 0 0 0
JP1 COLOUR1 0 0 0 0 0 0 0 0
JP0 COLOUR0 1 1 1 1 1 1 1 1
DISPLAY 520B9E0223 520B9E0223 520B9E1223 520BDE0223 520BDE1223 120BCA0221 120B8A0221 120BCA0221
0:LIGHT UP 1:FLASHING
