Sharp VC-GH61SM - Page 79

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
142
VC-GH61GM/SM,GH611GM
VC-GH60SM,GH600SM,GH601SM
VC-FH310GM/SM
DUNTKB111TEV3/V4
NICAM/IGR Unit
INTEGRATED CIRCUITS
IC1701 VHIMSP3407G-1Q V I.C. (FH310SM,GH60SSM, AS
GH601SM,GH61SM)
IC1701 VHIMSP3417G-1Q V I.C. (FH310GM,GH600SM, AY
GH61GM,GH611GM)
PACKAGED CIRCUITS
X1701 RCRSB0249GEZZ+ V Crystal AF
COILS
L1703 VP-XF100J0000+ V Peaking 10µH
L1704 VP-XF100J0000Y V Peaking 10µHAB
DUNTKB206TEV1
EUR-TERM Unit
INTEGRATED CIRCUITS
IC2501 VHILA73024V-1Y V LA73024V-TRM
TRANSISTORS
Q2903 VS2PB709AR/-1Y V 2PB709AR AB
DIODES
D2521 RH-EX0627GEZZY V Zener Diode AA
D2561 RH-EX0627GEZZY V Zener Diode AA
D2801 RH-EX0646GEZZY V Zener Diode AA
D2802 RH-EX0646GEZZY V Zener Diode AA
D2823 RH-EX0617GEZZY V Zener Diode AA
D2841 RH-EX0646GEZZY V Zener Diode AA
D2842 RH-EX0646GEZZY V Zener Diode AA
D2851 RH-EX0646GEZZY V Zener Diode AA
D2861 RH-EX0627GEZZY V Zener Diode AA
D2891 RH-EX0646GEZZY V Zener Diode AA
D2902 RH-EX0646GEZZY V Zener Diode AA
D2903 RH-EX0627GEZZY V Zener Diode AA
D2904 RH-EX0646GEZZY V Zener Diode AA
D2905 RH-EX0627GEZZY V Zener Diode AA
COILS
L2551 VP-XF3R3K0000Y V Peaking 3.3µH
L2591 VP-XF3R3K0000Y V Peaking 3.3µH
CAPACITORS
C2101 VCEA9M1HW105M+ V 1 50V Electrolytic AB
C2102 VCEA9M1HW105M+ V 1 50V Electrolytic AB
C2103 VCKYCY1HF103ZY V 0.01 50V Ceramic AA
C2501 VCEA9M1HW105M+ V 1 50V Electrolytic AB
C2502 VCEA9M1CW106M+ V 10 16V Electrolytic
C2503 VCCCCY1HH101JY V 100p 50V Ceramic AA
C2520 VCEA9M1CW107M+ V 100 16V Electrolytic AB
C2521 VCCCCY1HH101JY V 100p 50V Ceramic AA
DUNTB106TEX1/X2
OPERATION Unit
RESISTORS
R881 VRS-CY1JF103JS V 10k 1/16W Metal Oxide
R882 VRS-CY1JF103JS V 10k 1/16W Metal Oxide
R883 VRS-CY1JF223JS V 22k 1/16W Metal Oxide
MISCELLANEOUS PARTS
S881 QSW-K0004AJZZ+ V Switch, PLAY AB
S882 QSW-K0004AJZZ+ V Switch, STOP AB
S883 QSW-K0004AJZZ+ V Switch, REC AB
(FH310GM/SM)
S884 QSW-K0004AJZZ+ V Switch, REW AB
(except FH310GM/SM)
S885 QSW-K0004AJZZ+ V Switch, REW AB
(FH310GM/SM)
S886 QSW-K0004AJZZ+ V Switch, FF AB
(except FH310GM/SM)
S887 QSW-K0004AJZZ+ V Switch, FF AB
(FH310GM/SM)
SC881 QSOCZ0450CEZZ V Socket, 4pin(OA) AC
DUNTB107TEX1
BACK LIGHT Unit
TORANSISTORS
Q851 VS2PD601AR/-1Y V 2PD601AR AB
Q852 VS2PD601AR/-1Y V 2PD601AR AB
DIODES
D8851 RH-PXA021WJZZ+ V PhotoDiode AD
D8852 RH-PXA021WJZZ+ V PhotoDiode AD
D8853 RH-PXA021WJZZ+ V PhotoDiode AD
RESISTORS
R8853 VRD-RA2BE391JY V 390 1/8W Carbon
R8854 VRD-RA2BE391JY V 390 1/8W Carbon
R8855 VRS-CY1JF222JS V 2.2k 1/16W Metal Oxide
R8856 VRS-CY1JF222JS V 2.2k 1/16W Metal Oxide
R8857 VRD-RA2BE391JY V 390 1/8W Carbon
R8858 VRD-RA2BE391JY V 390 1/8W Carbon
R8859 VRD-RA2BE391JY V 390 1/8W Carbon
R8860 VRD-RA2BE391JY V 390 1/8W Carbon
MISCELLANEOUS PARTS
P883 QPLGZ0457GEZZ V Plug, 4pin(AM) AD
CAPACITORS
C1701 VCCSD41HL220JY V 22p 50V Ceramic
C1702 VCCCCY1HH470JY V 47p 50V Ceramic AA
C1704 VCKYCY1HF103ZY V 0.01 50V Ceramic AA
C1705 VCEA9M1CW106M+ V 10 16V Electrolytic
C1706 VCKYCY1HF103ZY V 0.01 50V Ceramic AA
C1707 VCEA9M1CW106M+ V 10 16V Electrolytic
C1708 VCEA9M0JW226M+ V 22 6.3V Electrolytic AB
C1709 VCEA9M1AW226M+ V 22 10V Electrolytic AB
C1710 VCCCCY1HH5R0CY V 5p 50V Ceramic AA
C1711 VCCCCY1HH6R0DY V 6p 50V Ceramic AA
C1712 VCKYCY1HF103ZY V 0.01 50V Ceramic AA
C1713 VCKYCY1HF103ZY V 0.01 50V Ceramic AA
C1714 VCEA9M1HW105M+ V 1 50V Electrolytic AB
C1715 VCKYCY1HF103ZY V 0.01 50V Ceramic AA
C1718 VCEA9M0JW226M+ V 22 6.3V Electrolytic AB
C1720 VCCCCY1HH470JY V 47p 50V Ceramic AA
C1723 VCEA9M1CW106M+ V 10 16V Electrolytic
C1730 VCEA9M1CW106M+ V 10 16V Electrolytic
C1731 VCEA9M1CW106M+ V 10 16V Electrolytic
C1735 VCKYCY1HB122KY V 1200p 50V Ceramic AA
C1738 VCKYCY1HB122KY V 1200p 50V Ceramic AA
RESISTORS
R1703 VRS-CY1JF473JY V 47k 1/16W Metal Oxide AA
R1710 VRD-RA2BE101JY V 100 1/8W Carbon
R1711 VRD-RA2BE101JY V 100 1/8W Carbon
R1714 VRS-CY1JF102JY V 1k 1/16W Metal Oxide AA
R1720 VRS-CY1JF103JY V 10k 1/16W Metal Oxide AA
R1723 VRS-CY1JF103JY V 10k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
SC1701QSOCZ0809REZZ V Socket, 8pin AC
