Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
145
VC-GH61GM/SM,GH611GM
VC-GH60SM,GH600SM,GH601SM
VC-FH310GM/SM
MECHANICAL PARTS
(EXCEPT VC-FH310GM/SM)
600 GCABA3169UMSW V Top Cabinet
601 GCABB1258AJNA V Main Frame
(except GH611GM(BK))
601 GCABB1258AJNB V Main Frame
(GH611GM(BK))
602 GCOVAA013WJZZ V Antenna Terminal Cover
603 XHPSD30P06WS0 V Screw AA
604 LANGK0261AJFW V Top Cabinet Fix Angel AC
605 XEPSD30P14XS0 V Screw
606 LX-HZ3047GEFF V Screw AA
607 XJSSF30P10000 V Screw AA
608 LX-HZ3098GEFF V Screw AB
609 LHLDZ2185AJ00 V Sensor LED Cover AB
610 UMS0026AJZZ V Foot Cushion AB
611 TLABM0167UMZZ V Model Label
612 GBDYU3145AJFW V Bottom Plate
613 XEBSD30P06000 V Screw AA
614 LHLDZ2184AJZZ V LCD Holder AC
616 PSLDM4594AJFW V H/A Shield AD
617 QEARPA016WJFW V Earth Plate
620 PSPAZ0600AJZZ V Spacer AB
ACCESSORIES
QCNW-7870UMZZ U 75ohm Coaxial Cable AH
TiNS-A083UMZZ U Operation Manual
(GH61GM/GH611GM)
TiNS-A091UMZZ U Operation Manual
(GH61SM)
TiNS-A084UMZZ U Operation Manual
(FH310GM/SM)
RRMCG1184AJSB V Infrared Remote Control
Unit (FH310GM/SM)
RRMCG1255AJSB V Infrared Remote Control
Unit (except FH310GM/SM)
ACCESSORIES( NOT REPLACEMENT ITEM )
SPAKP0051UMZZ - Foam Bag —
SPAKCA081WJZZ - Packing Case —
(GH61GM/SM,GH611GM)
SPAKCA076WJZZ - Packing Case —
(FH310GM/SM)
SPAKXA018WJZZ - Packing Pulp R —
SPAKXA019WJZZ - Packing Pulp L —
SUPPLIED ACCESSORIES
FRONT PANEL PARTS
(EXCEPT VC-FH310GM/SM)
500 CPNLCA003TEV1 V Front Panel Ass’y (GH60SM)
500 CPNLCA033TEV1 V Front Panel Ass’y (GH61GM)
500 CPNLCA004TEV1 V Front Panel Ass’y (GH61SM)
500 CPNLCA040TEV1 V Front Panel Ass’y (GH601SM)
500 CPNLCA041TEV1 V Front Panel Ass’y (GH600SM)
500 CPNLCA025TEV2 V Front Panel Ass’y
(GH611GM(BK))
500 CPNLCA025TEV1 V Front Panel Ass’y
(GH611GM(S))
500-1 ————————— - Front Panel —
500-3 HDECQA004WJSA V Cassette Flap (GH60SM)
500-3 HDECQA005WJSA V Cassette Flap (GH61GM)
500-3 HDECQA006WJSA V Cassette Flap (GH61SM)
500-3 HDECQA059WJSA V Cassette Flap (GH600SM)
500-3 HDECQA058WJSA V Cassette Flap (GH601SM)
500-3 HDECQA022WJSB V Cassette Flap (GH611GM(BK))
500-3 HDECQA022WJSA V Cassette Flap (GH611GM(S))
500-4 HDECQA042WJSA V Front Dec. (GH60SM,
GH61GM/SM)
MECHANICAL PARTS
(VC-FH310GM/SM)
600 GCABA3172AJSW V Top Cabinet
601 GCABB1257AJNB V Main Frame
602 GCOVA2230AJZZ V Antenna Terminal Cover
603 XHPSD30P06WS0 V Screw AA
604 LANGK0262AJFW V Top Cabinet Fix Angle
605 XJSSF30P10000 V Screw AA
606 LX-HZ3047GEFF V Screw AA
607 XEBSD30P12000 V Screw AA
608 LX-HZ3098GEFF V Screw AB
609 LHLDZ2185AJ00 V Sensor LED Holder AB
610 PGUMS0026AJZZ V Foot Cushion AB
611 TLABM0167UMZZ V Model Label
612 GBDYU3144AJFW V Bottom Plate
614 LHLDZ2184AJZZ V LCD Holder AC
616 PSLDM4594AJFW V H/A Shield AD
617 QEARPA016WJFW V Earth Plate
618 XEPSD30P14XS0 V Screw
619 XEBSD30P06000 V Screw
620 PSPAZ0600AJZZ V Spacer AB
500-6 HiNDP2237AJSC V Timer LED Indicator AD
(GH60SM,GH61GM/SM)
500-6 HiNDPA033WJSB V Timer LED Indicator
(GH611GM(BK))
500-6 HiNDPA033WJSC V Timer LED Indicator
(GH600SM,GH601SM,GH611GM(S))
500-7 MSPRD0105AJFJ V Cassette Flap Spring AB
500-10 JBTN-3164AJSA V Button, Pwer (GH611GM(BK)) AC
500-10 JBTN-3164AJSB V Button, Pwer
(GH600SM,GH601SM,GH611GM(S))
500-11 GCOVA2214AJZZ V R/C Cover (GH60SM,GH61GM/SM) AC
500-11 GCOVA2222AJZZ V R/C Cover AC
(GH600SM,GH601SM,GH611GM)
500-12 JBTN-3165AJSA V Button, CH (GH611GM(BK)) AC
500-12 JBTN-3165AJSB V Button, CH
(GH600SM,GH601SM,GH611GM(S))
501 JBTN-3159AJSA V Button, STOP/PLAY AC
(GH60SM,GH61GM/SM)
501 JBTN-3163AJSA V Button, STOP/PLAY AC
(GH611GM(BK))
501 JBTN-3163AJSB V Button, STOP/PLAY
(GH600SM,GH601SM,GH611GM(S))
502 JBTN-3162AJSA V Button, FF/REW AC
(GH60SM,GH61GM/SM)
502 JBTN-3166AJSA V Button, FF/REW AC
(GH611GM(BK))
502 JBTN-3166AJSB V Button, FF/REW
(GH600SM,GH601SM,GH611GM(S))
FRONT PANEL PARTS
(VC-FH310GM/SM)
500 CPNLCA027TEV1 V Front Pnel Ass’y
(FH310GM)
500 CPNLCA027TEV2 V Front Pnel Ass’y
(FH310SM)
500-1 Not Available - Front Pnel —
500-2 GCOVA2217AJSA V REC LED Cover
500-3 HDECQA034WJSA V Cassette Flap (FH310GM)
500-3 HDECQA035WJSA V Cassette Flap (FH310SM)
500-4 HDECQA036WJSA V Front Dec.
500-6 HINDPA018WJSA V LCD Indicator
500-7 MSPRD0105AJFJ V Cassette Flap Spring AB
500-11 GCOVA2214AJZZ V R/C Cover AC
501 JBTN-3158AJSA V Button, PLAY/STOP AC
