No.
Jig Item
Part No.
Code
Configuration
Remarks
This Jig is used with the tension
11
Tension Gauge Adapter
JiGADP003
BK
ecih
gauge. Rotary transformer
clearance adjusting jig.
12
Special Bladed Screwdriver
JiGDRiVERH-4
AP
This screwdriver is used for adjusting
the guide roller height.
13
Tension Band and Plate
JiGDRiVER-
BM
This Jig is used for adjusting the
Adjusting Jig
tension band and tension plate.
14
Torque Driver JiGTDl200
CB
This is used to screw down resin-
made parts: the specified torque is 5
kg-
This Jig is used for height
JiGDRiVER
10-7
AS
adjustment of the A/C head and X-
position.
15
Box Driver
JiGDRiVER
1
O-4
AV
&@
This Jig is used for height
0
adjustment of the retaining guide.
16
Reverse Guide Height Adjusting
JIGRVGH-F18
BU
This Jig is used for height
Jig
adjustment of the reverse guide.
17
To Next Page
