VT-341
8X
VT-5118X
REPLACEMENT OF LOCK RELEASE LEVER
l
Removal
1.
Place the slider in the cassette down position.
(Turn the coupling on the worm shaft clockwise
until the slider is in the cassette down position.)
Note:
Before shifting, unlock the slider.
2.
Slightly widen the cassette housing frames
(R)
and
(L)
to unhook the slider holders
(R)
and
(L)
of
the slider assembly off the grooves of the
cassette housing frames.
Pulley
(4
(b)
Figure l-l
7.
3.
Lift the slider holder
(R)
upward about
2mm
off
the slider by pressing two catches with a thin tip
screw driver.
Take care not to damage the
catches.
/-Slide
lock catch
4.
Remove the lock release lever from the slider
holder(R)
l
Reassembly
1.
Follow the steps for removal in the reverse order.
(See Figures
l-17
and
l-18.)
2.
Attach the lock release lever to the slider holder
00.
3.
Slide the slider holder
(R)
downward so that the
two catches of the slider holder
(R)
fit the
opening of the slider.
4.
Slightly widen the cassette housing frames, and
set the pins of slider holders
(R)
and
(L)
into the
grooves of the cassette housing frames.
Note:
Check if the pins of the slider holders
(R)
and
(L)
fit the grooves of the cassette housing frames,
and if the drive gear arm is sufficiently engaged
with the slider holders.
5.
Turn the coupling counterclockwise until the
slider is at the cassette insertion opening.
TO RUN A TAPE WITHOUT THE CASSETTE
HOUSING CONTROL ASSEMBLY
1.
2.
3.
4.
5
Plug in the power cord.
Turn on the power switch.
Open the lid
@
of a cassette tape by hand.
Hold the lid with two pieces of vinyl tape
Q.
Set the cassette tape in the mechanism chassis.
Stabilize the cassette tape with a weight
@
to
prevent floating.
Ined.
We
6.
0.)
7-
Perform running test.
Figure
l-1
8.
Note:
The weight should not be more than
500
g.
Figure
l-1
9.
23
