PRICE
RANK
DESCRIPTIONNO.
PART CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
XL-520H,520E/CP-520,520E
120 LANGT0026AWFW J AC Blacket,Hold
121 LANGT0027AWFW J AD Blacket,Motor
122 LANGT0033AWFW J AB Blacket,Switch
123 MSPRP0005AWFW J AB Spring,Cassette
124 MSPRC0008AWFJ J AB Spring,Back Tention
126 MSPRC0025AWFJ J AB Spring,Supply Cap
127 92LM-TSPR1756C J AB Spring,Lock Lever
128 MSPRD0033AWFJ J AB Spring,Play Idler Lever
129 MSPRD0034AWFJ J AB Spring,Play Roller
130 MSPRD0036AWFJ J AB Spring,Play Return
131 MSPRD0037AWFJ J AB Spring,Over Strok Lever
132 MSPRD0039AWFJ J AB Spring,FR Lever
133 MSPRD0040AWFJ J AB Spring,Eject Obstruct
134 NBLTK0030AWZZ J AC Belt,Sub
135 NBLTK0010AWZZ J AC Belt,Main
136 MSPRD0045AWFJ J AB Spring,Trigger Lever
137 RHEDH0001AWZZ J Head,Record/Playback
138 RHEDB0001AWZZ J AG Head,Erase
139 92LN-BAND1318A J AA Nylon Band,80mm
141 92LM-REL1676B J AB Cap,Supply Reel
501 92L1R8WC4-R5P J AA Washer,ø1.8×ø4×0.5mm
502 92L1R5WC3R8R5P J AA Washer,ø1.5×ø3.8×0.5mm
503 92L2TTS+4BZ J AA Screw,ø2×4mm
504 92L2TTS+5BZ J AA Screw,ø2×5mm
505 92LS2R6S1746A J AA Screw,ø2.6×5mm
506 92L2R3W3R4R25P J AA Washer,ø2.3×ø3.4×0.25mm
507 92L2R2TWO J AA Washer,ø2.2mm
508 LX-BZ0004AWFD J AC Screw,ø2.6mm Lock Lever
509 XHPSD20P05000 J AA Screw,ø2×5mm
M901 92LMTR2538AASY J AS Motor with Pulley [TAPE]
SOL901 RPLU-0002AWZZ J AH Solenoid Ass’y
SW901 92LM-SW1676A J AC Switch,Leaf Type
[Record Prevention]
SW902 92LM-SW1658A J AB Switch,Leaf Type [Cam]
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0010AWZZ J AC Rail,Guide
304 NSFTM0002AWFW J AE Shaft,Guide
305 92LM-CUSN1524A J AC Cushion,Gum
! 306 92LHPC1MXASY J Pickup Unit Ass’y
306- 1 ———— — Pickup Unit
(Not Replacement Item)
306- 2 NGERR0043AFZZ J AC Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
307 PCOVP1001AWSA J AE Cover,Mechanism
701 XBSSD26P06000 J AA Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 LX-WZ1070AFZZ J AA Washer,ø1.5×ø3.8×0.25mm
M801 92LMTR1854BASY J AP Motor with Gear [Sled]
M802 92LMTR1906CASY J AS Motor with Chassis [Spindle]
SW801 QSW-F9001AWZZ J AE Switch,Push Type [Pickup In]
CABINET PARTS
201 92LCAB2543AS1 J AV Front Panel Ass’y
201- 1 ———— — Front Panel
(Not Replacement Item)
201- 2 92LBADGE1692A J AC Badge,SHARP
201- 3 HDECQ0260AWSA J AK Panel,LCD
201- 4 GCOVH1010AWSA J AC Cover,Remote Control Sensor
202 LANGT0042AWFW J AC Bracket,PWB Support
203 92LCUSN1746A J AA Cushion,Leg
204 JKNBZ0382AWSA J AG Knob,Operation
204 LCHSM0058AWFW J AM Main Chassis
205 MLIFP0003AWZZ J AE Damper,Cassette Holder
206 MSPRD0093AWFJ J AB Spring,Cassette Holder
207 92LPNL2543AS1 J AM Cassette Holder Ass’y
207- 1 ———— — Cassette Holder
(Not Replacement Item)
207- 2 HDECQ0258AWSA J AF Panel,Cassette Holder
209 92LN-BAND1318A J AA Nylon Band,80mm
210 PCOVW1006AWZZ J AD Cover,PWB
211 92LCAUT1706A1 J AC Label,Class-3A Laser
212 92LCAUT1706B J AA Label,Laser
213 GCABB1168AWSA1 J AM Rear Panel
214 GITAS0037AWSA J AH Side Panel,Left
215 GITAS0038AWSA J AH Side Panel,Right
216 GCABC1164AWSA J AL Top Cabinet
217 PCOVS3020AWFW J AE Shield,Main PWB
218 GDORT0012AWSA J AG CD Lid
219 JKNBZ0128AWSB J AC Knob,CD Eject
220 92LLEV1651A J AB Lever,CD Eject Knob
221 MLIFP0003AWZZ J AE Damper,CD Lid
222 MSPRD0098AWFJ J AD Spring,CD Lid
223 92LMAG2538AS1 J AL Stabilizer Ass’y
223- 1 ———— — Stabilizer
(Not Replacement Item)
223- 2 92LCUSN1651A J AC Cushion,Stabilizer
223- 3 PMAGF0002AWZZ J AE Magnet
224
PRDAR0083AWFW1
J Heat Sink
225 LHLDZ1155AWZZ1 J Holder,LCD
226 LHLDZ1157AWZZ J AD Holder,LED
227 PSHEP0016AWZZ J AD Sheet,LCD
228 TLABS0136AWZZ J AB Caution Label,East Europe
[520H Only]
229 TSPC-0460AWZZ1 J Label,Specifications [520H]
229 TSPC-0461AWZZ J AE Label,Specifications [520E]
230 QFSHD0001AWZZ J AB Holder,Fuse
232 PCOVP1004AWSA J AG Cover,Heat Sink
233 PCOVS3019AWFW J AF Cover,Shield
237 PRDAR0082AWFW J AK Heat Sink
238 PSPAI0013AWZZ J AB Washer
239 92LRDAT-1468B J AE Heat Sink,Sub
241 GCOVD1003AWSB J AD Cover,Digital Out to MD/DAT
246 LANGF0030AWFW J AD Bracket,Heat Sink Support
601 LX-JZ0010AFFD J AA Screw,ø3×10mm
602 XESSD30P10000 J AA Screw,ø3×10mm
603 XHBSD40P06000 J AA Screw,ø4×6mm
604 XEBSD30P10000 J AA Screw,ø3×10mm
605 XJBSD30P10000 J AA Screw,ø3×10mm
606 XESSF30P12000 J AA Screw,ø3×12mm
607 XJBSF30P10000 J AA Screw,ø3×10mm
608 LX-EZ0005AWFD J AA Screw,Special
610 XJBSD30P08000 J AA Screw,ø3×8mm
612 XEBSF30P08000 J AA Screw,ø3×8mm
616 XJBSF30P08000 J AA Screw,ø3×8mm
ACCESSORIES/PACKING PARTS
1 QANTL0005AWZZ J AG AM Loop Antenna
2 SPAKA0146AWZZ J AL Packing Add.
3 SPAKC0562AWZZ J AQ Packing Case [520H]
3 SPAKC0563AWZZ J AQ Packing Case [520E]
4 SSAKH0014AWZZ J AB Polyethylene Bag,Unit
5 TINSE0177AWZZ J AE Operation Manual [520E]
5 TINSZ0249AWZZ J AT Operation Manual
[520H Except for Russian]
5 TINSZ0251AWZZ J AN Operation Manual
[520H For Russian]
6 TLABE0190AWZZ J AB Label,Bar Code [520H]
6 TLABE0191AWZZ J AB Label,Bar Code [520E]
7 TLABM0041AWZZ J AC Label,Feature [520E]
7 TLABM0052AWZZ J Label,Feature [520H]
8 92LBAG1460C1 J AB Polyethylene Bag,Accessories
9 92LBAG1658B J AA Polyethylene Bag,AC Power
Supply Cord
! 10 QACCB0004AW00 J BB AC Power Supply Cord [520E]
! 10 QACCE0005AW00 J AM AC Power Supply Cord [520H]
11 92LCARD1751A J AB Card,Registration [520E Only]
12 RRMCG0106AWSA J AX Remote Control
12- 1 GFTAB1017AWSA J Lid,Remote Control
13 92LF-ANT1535A J AF FM Antenna
P.W.B. ASSEMBLY (Not Replacement Item)
PWB-A1~6 92LPWB2543MANS J — Main/CD Servo/Display/LED/
Headphones/CD Lid Switch
(Combined Ass'y) [520E Only]
PWB-B1,2 92LPWB2543PWRS J — Power Amp/Power Supply
(Combined Ass'y) [520E Only]
PWB-C QPWBF0107AWZZ J AD Tape Mechanism (PWB Only)
[520E Only]
PWB-D QPWBF0027AWZZ J AD CD Motor (PWB Only)
[520E Only]
– 5 –
