Sharp XR-32S-L Service Manual

XR-32S-L/XR-32X-L/PG-F212X-L
23
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R1121 VRS-CY1JF471JY AA J Resistor 470 1/16W Metal Oxide
R1122 VRS-CY1JF220JY AA J Resistor 22 1/16W Metal Oxide
RMC1121 RRMCUA071WJZZ AN N J Remote Receiver
SLD1122 PSLDCA009WJFW AC J Shield Case Shield
[7] DUNTKE397WEF3 (PHOTO SENSOR Unit)
C1101 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
C1102 VCKYCY1EF104ZY AA J Capacitor 0.1 25V Ceramic
IC1101 VHiBA10393F2EY AD J IC BA10393F-E2
IC1102 VHPGP2S40//-1S AK J IC Photodiode
P1101 QPLGN0363TAZZY AC J Plug 3Pin (CW)
R1101 VRS-TQ2EF121JY AA J Resistor 120 1/4W Metal Oxide
R1102 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R1103 VRS-CY1JF153JY AA J Resistor 15k 1/16W Metal Oxide
R1104 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R1105 VRS-CY1JF000JY AA J Resistor 0 1/16W Metal Oxide
R1109 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R1111 VRS-CY1JF000JY AA J Resistor 0 1/16W Metal Oxide
R1112 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
[6] DUNTKE396WEF3 (R/C RECEIVER Unit)
