Sharp XR-32S-L Service Manual

XR-32S-L/XR-32X-L/PG-F212X-L
25
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[8] CABINET AND MECHANICAL PARTS
1 CBDYTA306WEF0 BQ N J Top Body Ass'y (XR-32S-L)
1 CBDYTA307WEF0 BF N J Top Body Ass'y (XR-32X-L)
1 CBDYTA308WEF0 BA N J Top Body Ass'y (PG-F212X-L)
1-1 Not Available - N - Top Body
1-2 GCOVAC364WJSA AE J R/C Cover
1-3 HDECPA034WJSA AK J Decoration Plate
1-4 HiNDPC319WJSA AN J Indicator (PG-F212X-L)
1-4 HiNDPC319WJSD AM J Indicator (XR-32S-L/XR-32X-L)
2 CBDYUA358WEF0 BR N J Bottom Body Ass'y (XR-32S-L)
2 CBDYUA359WEF0 BE N J Bottom Body Ass'y (XR-32X-L)
2 CBDYUA360WEF0 BE N J Bottom Body Ass'y (PG-F212X-L)
2-1 CDORUA075WEF0 AQ J Lamp Door Ass'y
2-1-1 Not Available - N - Lamp Door
2-1-2 LX-BZA185WJFN AB N J Screw
2-1-3 PSLDHA047WJFW AK N J Shield
2-2 Not Available - N - Bottom Body
2-3 LX-NZ3120CEFW AB J Nut (M5)
2-4 LX-NZ3144CEFW AC J Nut, x4 (M4)
2-5 LX-NZA014WJFW AC J Nut (M3)
2-6 QEARPA250WJFW AK J Bottom Earth Shield
2-7 GLEGPA030WJSA AK J Foot (Rear Adjuster)
2-8 GLEGPA036WJSA AP J Foot (Front Adjuster)
2-9 PSPAZB478WJZZ AC J Adjuster Spacer
2-10 QCNW-F721WJQZ AN J Connecting Cord (Leaf Switch)
2-11 XEBSN30P10000 AA J Screw
4 Not Available - N - Refer to Optical Mechanism Parts
5 AN-F212LP - N - Lamp Unit (Option)
6 LHLDFA011WJKZ AC J Rivet (Power PWB)
8 LHLDZA849WJKZ AQ J Holder (Bimetal)
9 LX-BZ3049GEFN AB J Screw, x2
10 LX-BZ3100CEF7 AA J Screw (XR-32S-L/XR-32X-L, x10) (PG-F212X-L, x9)
12 LX-BZA186WJF9 AD J Screw, x2
14 NFANRA076WJ00 BM J Fan
15 NFANRA078WJ00 BP J
Power Fan
16 PCOVPA037WJSA AU J Cover (Focus Ring) (XR-32X-L/PG-F212X-L)
16 PCOVPA037WJSB AM J Cover (Focus Ring) (XR-32S-L)
17 PCOVUA105WJ00 AF J Button Cover
18 PCOVZA106WJZZ AH J Irrigation Cover
19 PCOVWA015WJKZ AC J Spacer
22 PSLDMB281WJFW AH J Terminal Shield
23 PSLDMB313WJFW AH N J Main PWB Shield (PG-F212X-L)
24 PSLDMB284WJFW AY J Power Shield (Bottom)
25 PSLDMB285WJFW AW J Power Shield (Top)
26 PSPAGA370WJKZ AP J Spacer (Speaker)
27 PSPAGA371WJKZ AW J Spacer (Fan)
28 PZETKA298WJKZ AK J Insulator
29 PZETKA297WJKZ AK J Insulator
!
33 QCNW-G870WJPZ AS J Connecting Cord (Bimetal)
34 QCNW-F720WJQZ AG N J Connecting Cord (Photo Unit)
37 RSP-ZA085WJQZ AP J Speaker
38 XBBSN30P06000 AA J Screw
39 XBPSN30P08JS0 AB J Screw, x3
40 XEBSN30P10000 AA J Screw, x17
41 Not Available - N - Serial No Label
42 PCOVZA114WJKZ AD J Vent Cover
43 QEARPA299WJFW AC J Earth Plate (XR-32S-L/XR-32X-L)
44 QCNW-G254WJQZ AH J Connecting Cord (R/C Wire)
45 NSFTZA261WJFW AC J Shaft , x2(XR-32X-L/PG-F212X-L)
46 LANGFA508WJFW AD J Fan Angle
48 GCOVAC615WJKA AV J Exhaust Cover (XR-32X-L/PG-F212X-L)
48 GCOVAC615WJKB AV J Exhaust Cover (XR-32S-L)
49 LHLDW1226CEZZ AC J Holder
