Sharp XR-32S-L Service Manual

XR-32S-L/XR-32X-L/PG-F212X-L
27
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[9] OPTICAL MECHANISM PARTS
4-1 LANGKB121WJFW AE J Fixing Metal
4-2 LCHSKA025WJFW BQ N J Chassis
4-3 LHLDZA845WJKZ AN J Holder
4-4 LX-EZA027WJFN AC J For Focus Ring, x3
4-5 MSPRPA095WJFW AF J Spring
4-6 MSPRPA096WJFW AG J Spring (XR-32X-L/PG-F212X-L)
4-6 MSPRPA102WJFW AG N J Spring (XR-32S-L)
4-7 MSPRPA097WJFW AK J Spring
4-8 NFANRA077WJ00 BH J Fan
4-9 PCOVPA036WJSA AR J Cover (XR-32X-L/PG-F212X-L)
4-9 PCOVPA036WJSB AN J Cover (XR-32S-L)
4-10 PCOVPA038WJSA AS J Cover (XR-32X-L/PG-F212X-L)
4-10 PCOVPA038WJSB AN J Cover (XR-32S-L)
4-11 PCOVZA110WJFW AK N J Cover
4-12 PCOVZA093WJKZ AM J Cover
4-13 PCOVZA094WJKZ AN J Cover
4-14 PCOVZA095WJFW AL J Cover
4-15 PCOVZA096WJFW AG J Cover
4-17 PFiLWA120WJZZ BM J Color Wheel (XR-32S-L/XR-32X-L)
4-17 PFiLWA146WJZZ BT N J Color Wheel (PG-F212X-L)
4-18 PLNS-A089WJZZ BB N J Lens (Rod)
4-19 PLNS-A080WJZZ AT J Lens (Pj )
4-20 PLNS-A083WJZZ AT J Lens (L1)
4-21 PLNS-A084WJZZ AT J Lens (L2)
4-22 PLNS-A085WJZZ BD J Lens (L3)
4-23 PMiR-A125WJZZ AU J Mirror
4-24 PRDARA446WJFW AQ J Heat Sink
4-25 PSLDHA048WJFW AK J Fan Shield
4-26 PSLDPA081WJFW AM N J Shield (DMD Aperture)
4-27 PSLDPA072WJKZ AZ J Shield (Lamp Barrier)
4-28 PSLDPA073WJFW AD J Shield (Rod Ap)
4-29 RH-HXA040WJQZ AS N J Thermistor
4-30 TLABZB026WJZZ AE J No. Label
4-31 XBBS925P06000 AA J
Screw, x9
4-32 LX-BZA205WJFN AA J Screw, x3
4-33 XBBSN30P06000 AA J Screw, x20
4-34 XBPSN30P20JS0 AB J Screw, x2
4-35 XEPSN17P05000 AB J Screw, x2
4-36 PSLDPA078WJFW AF J Shield
4-37 PSPAHB664WJZZ AD N J Spacer
4-38 PSLDPA087WJKZ AC N J Dust Shield
11 LX-BZA224WJF7 AB J Screw, x3
13 MSPRCA076WJFJ AC J Spring, x3
20 PRDARA535WJFW AX J Heat Sink
21 PSHEZA077WJZZ AL J Sheet
36 RDMDPA029WJZZ CU J DMD Chip, 0.55" SVGA (XR-32S-L)
36 RDMDPA035WJZZ DB J DMD Chip, 0.55" XGA (XR-32X-L/PG-F212X-L)
