- 3 -
8. Unlock the safety switch and press the trigger. The compressor will now inflate your tire to
your pre-set pressure level. Then, it will shut off automatically.
9. Press the trigger of the compressor to stop the compressor if necessary.
10. Remove the thread connector from the tire or object after it is fully inflated.
INSTRUCTIONS FOR USE
–
BATTERY POWER
NOTE: You must charge your air compressor fully before the initial use. A full charge can take up
to 4 hours. To check battery level, insert the battery into the air compressor and press the Unit
button (center button). Normal charging time: 4 hours.
1. Remove the battery from the air compressor by gripping the end of the battery and pulling it
out.
2. Charge the battery with the included AC charger. Plug the charger into any standard AC
outlet. NOTE: Do not use any other charger. Use only the charger that came in this package.
3. When the battery is fully charged, you may begin inflation using steps 2-10 above.
SPECIFICATIONS
Operating voltage DC11.1~DC12V
Maximum current Less than 12A
Inflation efficiency Inflates a typical car tire (185/70R14) from 0 to 30 psi
in 6 minutes
Maximum inflation pressure 120 PSI
Pressure gauge accuracy ±0.5 PSI
Lithium battery capacity 2200mAh
Charging time 4 hours
Length of hose 4.7”
Operating temperature 32°F to 140°F
Product size 3” L x 3.3” W x 10.4” H
Product weight 2.75 lbs.
