1. Remove the plastic packing materials from the light fixture.
2. Remove the foam shipping guard from behind the pre-
installed lamp.
Note:
The lamp socket (containment barrier) pivots out.
Be certain to push the lamp and socket back into the fixture.
(See Figure A below.)
3. To adjust the lamp height and angle, loosen the knobs on the
fixture arms and move the arms to the desired height and
angle, then tighten the knobs to secure the new positions.
Figure A
Assembly
