4
3. GENERAL DESCRIPTION
Semi-automatic MIG welder 200M is used for manual welding of steel and non-ferrous metals MMA (covered electrode) and MIG / MAG
gas-shielded self-shielded wire or without shielding gas. It can also be used to braze thin (3mm) galvanized sheets. It can be used indoors or covered,
if directly exposed to weathering. Works with D200 wire spools (5kg).
Option MIG / MAG handle Spool gun (SG) to connect grip SG is mounted at the mini wire feed reel and D100 steel wire or colored, so that
welding can be two different wires without the need for retooling welder. The choice of the holder takes place via the mode switch. It is a time-saving
solution for the need for welding different materials or different thicknesses up casual use of wires.
4. SPECIFICATIONS
4.1 welder
Power supply: AC 230V 50Hz
Rated welding current / cycle 200 A (MIG); 185 A (MMA) / 60%
Range of welding current 30-200 A (MIG); 17-185 A (MMA)
The maximum current for welding handle Spool Gun 130 A
The diameter of the spool of wire: 100 mm, 200 mm
The adjustment range of wire feed speed 1,5-19 m / min
Maximum current consumption / power 37.4 A / 8.8 kVA
Mass: 21 kg
dimensions: 500 x 260 x 540 mm
Level of security IP21
4.2 MIG
handle type TW-15
The maximum current carrying capacity 200 A
Type of cooling shielding gas
The cooling gas flow 10-18 l / min
Length 3 m
4.3 Spool Gun Bracket (optional)
http://tecweld.pl/downloads/uchwyt-spool-gun-m-15-ulotka.pdf
handle type Gun spool 15 (MTMSG3M)
The maximum current carrying capacity 150 A
The recommended diameter of the welding wire 0.6-1.0 mm
Wire feed speed 1-13 m / min
Length 3 m
