OWNER’S MANUAL
820–133
Rev
D
Supersedes
C AND PCN D
1/4 GALLON PER MINUTE, 120 V
AC, 60 HZ
SHERWIN–WILLIAMS
PT2500
Electric
Airless Paint Sprayer
3000 psi (210 bar) Maximum Working Pressure
Model 820–113, Series C
Complete
Sprayer with hose and gun.
U.S.
Patent No. 4,616,982
U.K. Patent No. 2,165,591
Other Foreign Patents Pending
The
SHER
WIN-WILLIAMS COMPANY, CLEVELAND, OHIO 44115
COPYRIGHT 1991, GRACO INC.
This
manual contains important
warnings and information.
READ AND RETAIN FOR REFERENCE


Table of Contents

Questions and Answers

  • L
    Lisa MerrittJul 30, 2025
    Why won't my Sherwin-Williams Paint Sprayer spray gun shut off?
    • S
      Stephen OliverJul 30, 2025
      If your Sherwin-Williams Paint Sprayer gun won’t shut off, it could be due to several reasons: a worn ball, a worn diffuser, or paint build-up between the needle and diffuser. To resolve this, you can try the following: * For a worn ball: Repair the gun using kit no. 218–588. * For a worn diffuser: Replace the gun. * For paint build-up: Disassemble and thoroughly clean the gun.
  • M
    Michelle BakerAug 8, 2025
    What to do if my Sherwin-Williams PT2500 Paint Sprayer has a poor spray pattern?
    • M
      Michael PerezAug 8, 2025
      A poor spray pattern in your Sherwin-Williams Paint Sprayer can be caused by a worn spray tip or paint that is too thick. To fix this, try changing the tip or thinning the paint and using a larger tip.
  • J
    johnnymorganAug 19, 2025
    Why is my Sherwin-Williams PT2500 Paint Sprayer gun leaking?
    • J
      Joseph NixonAug 19, 2025
      A leaking Sherwin-Williams Paint Sprayer gun is typically caused by a worn seal or a loose fluid fitting. You can try repairing the gun with kit no. 218–588 or tightening the fluid fitting.
