Introduction 1
Notice to Users, Installers, Authorities Having Jurisdiction, and other involved parties. This product incorporates
field-programmable software. In order for the product to comply with the requirements in the Standard for Control
Units and Accessories for Fire Alarm Systems, UL 864 9th Edition, certain programming features or options must be
limited to specific values or not used at all as indicated below.
Reference Appendix B, “Equipment List” for model designations of the devices contained in this table.
Program Feature or Option Permitted in UL 864 ?
(Y / N)
Possible Settings Settings Permitted
In UL 864
AC Fail Delay Yes 0 - 24 hours 1 - 3 hours
Alarm Verification Yes 5 - 60 seconds 60 second
Disable Buzzer Yes Enable / Disable Enable
Disable Ground Trouble Yes Enable / Disable Enable
Set Buzzer Silence Access Level Yes 1 or 2 2
NAC Output Delay Stage 1 No 0 - 5 minutes 0 minutes
NAC Output Delay Stage 2 No 0 - 5 minutes 0 minutes
Photoelectric Smoke Sensor
Delay
No 0 -120 seconds 0 seconds
Ionization Smoke Sensor Delay Yes 0 -120 seconds 0 seconds
Duct Detector Yes 0 -120 seconds 0 seconds
Duct Detector with Relay Yes 0 -120 seconds,
0 - 5 seconds
0 seconds
Contact Module Delay
(All models)
Yes 0 -120 seconds 0 seconds
Relay Module Delay Yes 0 - 5 seconds 0 seconds
Supervised Output Module Delay Yes 0 - 5 seconds 0 seconds
Section 1
Introduction
Shield Fire, Safety and Security Ltd.
Shield Omega - X Panel Installation Manual
SH3514-00, Revision E03.04
Issue Date: 1 April 2014
Page 1 of 118
