The Shield Omega-X Panel is a sophisticated fire alarm control panel designed for comprehensive fire detection and reporting. It operates using the Apollo protocol for its Signaling Line Circuits (SLC) devices and is available in both 2-loop and 4-loop models. The 2-loop models include the No Communication SA-P20 and the Network Interface Card (Omega-N) SA-P2E, while the 4-loop models offer the No Communication with Loop Expansion SA-P4L and the Network Interface Card (Omega-N) with Loop Expansion SA-P4E. These panels are capable of accepting a variety of industry-standard devices for Fire Alarm Control Panel (FACP) monitoring and reporting. They can also be linked with other panels using the proprietary Omega-N to monitor conditions between panels and provide reports to monitoring centers via a standard TELCO line.

Function Description:

The Omega-X Panel serves as a local signaling unit and supports releasing functions for Omega-X Panels only (non-releasing for other Omega-X Panels). It handles automatic fire alarms, manual fire alarms, waterflow alarms, and sprinkler supervisory services. The panel supports Style 4, 6, or 7 for Signaling Line Circuits and Style Y for Notification Appliance Circuits. It features non-coded signaling and includes an integrated dialer for DACT (Digital Alarm Communicator Transmitter) functionality. The panel can be configured for Remote Station (RS) Protected Premises Unit (PPU) Omega-N communication, Central Station (CS) Protected Premises Unit (PPU) Omega-N communication, and Proprietary (P) Protected Premises Unit (PPU) with releasing, non-releasing, and Omega-N communication. These communication options are available for models SA-P20XX, SA-P2EXX, SA-P4LXX, and SA-P4EXX, each with a Modem DACT SA-DACT.

Important Technical Specifications:

The Omega-X Panel supports a maximum of 126 points per loop without subpoints or 381 points per loop when utilizing subpoints. The total addressable capacity for the panel is 800 addresses (points and subpoints). When using the Contact ID digital communication format for monitoring-center communication, there are address restrictions. Analog-sounder-bases should not be assigned using the Contact ID format, as its address range is insufficient for reporting their status. The Contact ID format limits reporting to an address of 99. While the eSP Discovery application restricts the use of Contact ID for addresses above 99, it can be used for other devices as long as their address and sub-address are below 99. For situations where the 99-address limit per loop cannot be avoided, FACP reporting can be switched from point reporting to zone reporting, though this reduces overall reporting granularity. The panel can be programmed for either SIA or Contact ID digital communication formats, both providing status monitoring and reporting to industry-standard receivers. The eSP Discovery application uses an open protocol for assigning device addresses.

The panel's internal components include a Modem-DACT, a Control Unit Board, a 4 Amp OEM 1 Power Supply, a Panel Annunciator Board, and Batteries.

Usage Features:

The front panel of the Omega-X features an LCD display, upper-control-pad, lower-control-pad, left-panel-indicators, and right-panel-indicators.

Upper-Control-Pad functions:

Central keypad number four (left arrow): Navigates menu selections to the left.
More Fire Events: Displays the number of alarms and overrides menu navigation.
Exit: Cancels the current menu selection.
Central keypad question mark (?): Provides a "help screen" for the current menu display and status information (e.g., recommendations during alarm/fault conditions).
Central keypad number three (down arrow): Navigates menu selections down.
Enter: Enables the menu selection.
More Events: Displays the number of events (Fire, Pre-Alarm, Trouble, Disablements, Other) and overrides menu navigation.
Central keypad number two (right arrow): Navigates menu selections to the right.
Central keypad number one (up arrow): Navigates menu selections up.

Lower-Control-Pad functions:

Re-Sound Alarm: Re-sounds the alarm if sounders were muted using Alarm Silence.
Alarm Silence: Silences NACs after Access Level 2 authorization.
Panel Sounder Silence: Mutes the internal buzzer; does not affect other sounder outputs.
Lamp Test: Tests front-panel indicators and internal buzzer by illuminating all LEDs, darkening the display, and sounding the buzzer.
Reset: Resets latching inputs (fire, pre-alarm events) after Access Level 2 authorization. Fault events are non-latching and clear when faults are cleared.
Fire Drill: Initiates a fire drill after Access Level 2 authorization. During a drill, the "On Test" LED illuminates, "Fire" LEDs blink, the internal buzzer sounds intermittently, and the display shows "FIRE DRILL:FIRE DRILL ZONE 00*". To stop, press 4 for "SET ACCESS LEVEL 2 MENU", provide Access Level 2 authorization, then press Reset or Fire Drill.
Programmable Function: Activates inputs, outputs, or actions defined in the configuration.

Programming Features (UL 864 9th Edition Compliance):

Certain programming features must be limited for UL 864 9th Edition compliance:

AC Fail Delay: Permitted in UL 864 (Y), Possible Settings (0-24 hours), Settings Permitted in UL 864 (1-3 hours).
Alarm Verification: Permitted in UL 864 (Y), Possible Settings (5-60 seconds), Settings Permitted in UL 864 (60 seconds).
Disable Buzzer: Permitted in UL 864 (Y), Possible Settings (Enable/Disable), Settings Permitted in UL 864 (Enable).
Disable Ground Trouble: Permitted in UL 864 (Y), Possible Settings (Enable/Disable), Settings Permitted in UL 864 (Enable).
Set Buzzer Silence Access Level: Permitted in UL 864 (Y), Possible Settings (1 or 2), Settings Permitted in UL 864 (2).
NAC Output Delay Stage 1 & 2: Not permitted in UL 864 (N), Possible Settings (0-5 minutes), Settings Permitted in UL 864 (0 minutes).
Photoelectric Smoke Sensor Delay: Not permitted in UL 864 (N), Possible Settings (0-120 seconds), Settings Permitted in UL 864 (0 seconds).
Ionization Smoke Sensor Delay: Permitted in UL 864 (Y), Possible Settings (0-120 seconds), Settings Permitted in UL 864 (0 seconds).
Duct Detector: Permitted in UL 864 (Y), Possible Settings (0-120 seconds), Settings Permitted in UL 864 (0 seconds).
Duct Detector with Relay: Permitted in UL 864 (Y), Possible Settings (0-120 seconds, 0-5 seconds), Settings Permitted in UL 864 (0 seconds).
Contact Module Delay (All models): Permitted in UL 864 (Y), Possible Settings (0-120 seconds), Settings Permitted in UL 864 (0 seconds).
Relay Module Delay: Permitted in UL 864 (Y), Possible Settings (0-5 seconds), Settings Permitted in UL 864 (0 seconds).
Supervised Output Module Delay: Permitted in UL 864 (Y), Possible Settings (0-5 seconds), Settings Permitted in UL 864 (0 seconds).

Maintenance Features:

The manual provides instructions for routine service and repair, including inspecting and replacing standby batteries, and replacing fuses (10 Amp Battery Fuse and 3 Amp Power-Supply Fuse). It also covers replacing internal and cabinet components. For technical support, Shield Fire, Safety and Security Ltd. can be contacted via phone or email. The company offers a limited returns and repairs policy, including in-warranty items, damaged goods, and component failure. Service Replacement Items (SRI) are available for replacement parts under warranty, provided certain conditions are met regarding return of faulty parts and packaging. Out-of-warranty items can be tested and repaired, subject to component availability and customer authorization. Items returned for credit are accepted within the first 3 months of supply, requiring an RMA reference number and adherence to specific return procedures.

Installation Guidelines (NFPA and UL Compliance):

Installation must comply with NFPA 13, NFPA 72, NEC 70, and all local codes.

Short Circuit Isolator Modules: Required for SLC loops wired with Class A Style 7 to protect devices from single-loop shorts. Closed nippling and conduit nippling are necessary to maintain compliance with individual enclosures. For Class A Style 6, isolator modules can be strategically located.
TELCO Lines: NFPA requires two dedicated and independent TELCO lines for communication features like the Integrated Dialer.
SLC Detectors: Spacing should follow UL 864, 9th edition, section 90.19. For multiple detector operation, a minimum of two detectors per protected space is required, and spacing can be reduced to 0.7 times the linear spacing as per NFPA 72. Refer to UL 864, 9th edition, sections 55.3.1 and 55.3.2 for detector spacing requirements.
Field Wiring: Must use fire-rated cables according to NFPA 72.
Riser Conductors: Must be installed in accordance with NFPA 72, sections 6.8.6.3 and 6.9.4, ensuring survivability from fire attack. This involves either a 2-hour rated cable system, AHJ-approved requirements, or installation of the Supervised Output Module using NFPA Style 7 configuration.

The manual also includes appendices for specifications (electrical, SLC ratings, programmable relay contact ratings, power output circuits, unsupervised inputs, RS485 serial bus, auxiliary 24 VDC, Omega-N terminals, 4 Amp OEM 1 power supply, AC line connection, cabling, operating environment, physical specifications), an equipment list (Shield Omega-X Panels, loop devices, accessories, replacement parts, compatible notification appliance circuits, authorized special application devices, compatible devices for auxiliary 24V), current draw calculations, a door label copy, and operating instructions.
