Shihlin electric BA Series User Manual

ACB-I
12
I N S T R U C T I O N S
4.1.2.6 MCR make-break and overstep tripping (optional)
Make-break and overstep tripping protections are parts of back-up functions, which are optional. They
are both instantaneous tripping actions whose tripping value relate to their service breaking and ultimate
breaking capacities. Usually, MCR current is 40KA, 60KA, 80KA, overstep tripping current is 50KA, 75KA,
100KA(especially for
Type DW40,45,48 breaker, the factory defaults of current values are 40/50KA for Frame
I, 60/75KA for Frame II, 80/100KA for Frame III). Fault current signal sends out tripping instruction directly by
hardware comparison circuit. MCR make-break protection works only at the moment of making (about 100
ms), while overstep tripping is available all the time.
4.1.2.7 System clock adjustment function (
optional)
The controller can be added function of system clock adjustment, to record time and date when the fault
generated. This function automatically eectiveness once is chosen. Details of the function of system clock
adjustment considering chapter7.2.3.5
4.1.2.8 Signal contact output function (optional)
The controller output 4 groups of signal separately, this function realized by programmer or
other special ways.
The provided signal contacts output function and output time indicated as table 7.
Defaulted states of the controller's 4 groups signal contacts output function indicated as table 8.
Table 7 : Controller's signal contacts output function and output time
Serial number Signal contact output function Signal contact output time
0 No denition No output
1 Trip and alarm if short circuit fault instantaneous fault
Output when short circuit instantaneous fault trip
occurs
2 Trip and alarm if earthling or leakage fault Outputting when grounding or leakage fault trip occurs
3 Trip and alarm if unbalance current fault Outputting when unbalanced current fault trip occur
s
4 Trip and alarm if short circuit short time delay fault
Outputting when short circuit short delay
fault trip occurs
5 Trip and alarm if overload long time delay fault Outputting when overload long delay fault trip occurs
6 Trip and alarm if fault Outputting when any fault trip occurs
7 Unoverload output if overload monitor 1 Outputting when overload monitor 1 time over
8 Unoverload output if overloa
d monitor 2 Outputting when overload monitor 2 time over
9 Alarm if system self-diagnose Outputting when system self-diagnose fault occurs
10(A) Alarm if power grid in fault state
Outputting at beginning of protection or
monitor delay operation
Table 8 : Defaulted function states of 4 group's contacts in controller
Note : Contact 3 and contact 4 for Type 2H controller are xed just for remote break and re
mote make
Contact number
Controller type
Contact 1 Contact 2 Contact 3 Contact 4
Type2M
Overload monitor 1
unoverloadoutput
Overload monitor 2
unoverload output
system
self-diagnose fault
alarming
fault tripping and
alarming
Type2H
Overload monitor 1
unoverload output
Overload monitor 2
unoverload output
Remote breaking Remote making
Contact number
Controller type
