2. Packing List and Component Names
2.
Packing List and Component Names
2.1 Packing list
Unpack and verify that the following standard packed items (one each) are present.
Connection Cable
Printer Main Unit
Printer Paper and
Printer Paper Shaft
Instruction manual
AC Adapter
The shape of the supplied AC adapter may differ from the figure above.
2.2 Main unit components
(1) Power switch (2) Command keys (3) Printer paper cover (4) Power connector
(5) Data I/O connector (6) Battery cover (7) LOW BATT lamp (8) Power indication lamp
(9) Statistics lamp (10) Auto print lamp (11) Cutter
5
