Shimano FD-M980 - XTR Front Derailleur Model Overview; FD-M980 Parts and Diagram; FD-M980-E Parts and Diagram; FD-M980-E (without BB-Plate) Parts

XTR Front Derailleur for Triple
FD-M980
FD-M980
-E Bracket Type
ITEM
NO.
1
Y5M407000
Clamp Bolt (M5 x 17)
2
Y5M498010
Cable Fixing Plate & Bolt (M5 x 9) A
Y57Y98030
SM-AD17S Clamp Band Adapters for S-size / φ28.6 mm (1-1/8") A
Y57Y98040
SM-AD17M Clamp Band Adapters for M-size / φ31.8 mm (1-1/4") A
4
Y5M498020
Stroke Adjust Screws (M4 x 8.5) & Plate
5
Y5K498020
Bracket Fixing Bolt Unit A
6
Y5M550000
BB-Plate
A: Same parts. Jun.-2010-3079
B: Parts are usable, but differ in materirals, appearance, finish, size, etc.
©
Shimano Inc.
A
Absence of mark indicates non-interchangeability.
Specifications are subject to change without notice.
3
INTERCHANGEABILITY
SHIMANO
CODE NO.
DESCRIPTION
F
D
-
M
7
7
0
-
1
0
F
D
-
M
9
7
0
-
E
