Settings:
P01: Brightness Backlight display: 1=darkest, Stand 2=mid, Stand 3=brightest.
P02: Setting for speed display: KM=0, MILE=1
P03: Voltage setting: 24V, 36V, 48V, (36V = standard default)
P04: Standby time: 0 =no standby; other values indicates the number of minutes.
P05: Assistance gear (voltage signal values)
0, 3Mode: 1lever2V、 2lever3V、 3lever 4V, 4lever 5V, 5levelr6V
1, 5Mode: 1levelr2V、2lever 2.5V、3lever 3V, 4lever 3,5V, 5lever 4V
P06: Wheel diameter: unit= inches (Accuracy=0.1)
P07: Speed measuring magnetic steel number: range: units: 1-100 (do not change)
P08: Speed setting from 0-50 KM/HR (default 50. This value does not indicate speed limit)
Note: When the speed is greater than the set speed, shut off the PWM output; When speed down to less than the set
speed, automatically open the PWM output, driving speed to the current + 1 km/h; Numerical based on km as a
benchmark here, after the unit set from miles to miles, display the speed of numerical value is automatically
converted to the correct miles, but miles under the interface of the menu in the values of speed limit set by the data
conversion, MPH speed limit values are not consistent with the actual display
P09: Startup setting from Stop. 0=Start, 1=Don’t start
P10: Drive mode setting:
0= Power drive. (decided how much output power by power gear, at this time to turn the invalid)
1= Electric (by going to drive, steering gear is invalid at this time)
2= Power drive and electrical drive coexist (electric zero start state is invalid. This option turns P09 off)
P11: Power sensitivity setting range: 1-24.
P12: Assistance start the intensity setting range: 0-5
P13: Power magnetic steel plate type 5 Sherwin grain of magnetic steel three types
P14: Controller for the current limit value to set,12A (by default) range: 1 - 20 A
These standard settings apply for Europe with the exception of the U.K.:
P01=3, P02=0, P03=36, P04=0, P05=1, P06=20, P07=1, P08=25, P09=1, P10=2, P11=2, P12=1, P13=8, P14=14
