Model:SRH-P186DC
No. Part No. Part Name Q’ty Remark
1 1083520101 Grille 1
2 1081990056 Top Cover 1
3 214115531 Condenser 1
4 1081990060 Outdoor Motor Supporter 1
5 1170040118 Outdoor Motor 1
6 1070030028 Propeller Fan 1
7 1081990053 Left Grille Supporter 1
8 1081990058 Front Plate 1
9 1081990059 Fan Guard 1
10 1100060147 Compressor And It Accessories 1
11 1120500226 4-way Valve 1
12 1120520680 4-way Valve Assembly 1
13 210800571 Base 1
14 1081990054 Right Plate 1
15 1120120021 Two-way Valve 1
16 1081990055 Valve Supporter 1
17 1120130032 Three-way Valve 1
18 1070350971 Electrical Box Cover 1
19 1070040008
Cable Clamp(φ10)
1
20 1170200061 Terminal 1
21 1080520142 Electrical Parts Box 1
22 1090320295 PFC Board 1
23 1090520620 Inverter module 1
24 1090520619 Power source board 1
25 1170330004 Radiator 1
26 1170190002 Inductor 1
27 1120520685 Capillary assembly 1
28 1081990095 Partition plate 1
29 1170230007 Pipe Temp. sensor and outdoor
Temp. sensor
1
30 1170230006 Discharge Temp. sensor 1
31 211312854 Base Carton 1
32 211312855CZ Cabinet Carton 1
33 211312852 Base Foaming 1
34 211312851 Cover Forming 1
Air Conditioner Service Manual
Not shown in explosion view
21
