RECOMMENDED FASTENER TORQUE
7
OPERATIONS AND SERVICE MANUAL
FASTENER TORQUES
All fasteners are prone to becoming loose from sustained high-performance use. SHOCKWAVE recommends that
all bolts should be visually inspected for signs of being loose. Always use a thread-locker on fasteners to prevent
loosening. Please use the reference table below:
SIZE PITCH TORQUE (STAINLESS)
Dry
#6
M5
#8
M6
M8
M10
M12
5/16”
5/8”
3/8”
3/4”
7/16”
1”
#10
1/4”
1/2”
32
0.8
32
1.0
1.25
1.5
1.75
18
11
16
10
14
8
24
20
13
32
28
20
10 in-lbs
45 in-lbs
21 in-lbs
6 ft-lbs
15 ft-lbs
31 ft-lbs
54 ft-lbs
11 ft-lbs
96 ft-lbs
20 ft-lbs
131 ft-lbs
32 ft-lbs
299 ft-lbs
23 in-lbs
6 ft-lbs
45 ft-lbs
33 in-lbs
8 ft-lbs
47 ft-lbs
9 in-lbs
40 in-lbs
17 in-lbs
6 ft-lbs
14 ft-lbs
27 ft-lbs
48 ft-lbs
9 ft-lbs
82 ft-lbs
17 ft-lbs
111 ft-lbs
27 ft-lbs
254 ft-lbs
20 in-lbs
6 ft-lbs
38 ft-lbs
28 in-lbs
7 ft-lbs
40 ft-lbs
IMPERIAL
METRIC
Lubricated
To Next Page
