Dust Collector 330002
Page 2
Parts List
29 518393 Retaining Strap Assembly ................... 1
30 300006 Bag, Package of 6 ................................... 1
31 514831 Hex Head Cap Screw, ¼-20x1-3/8” ...... 4
32 120380 Spring Lock Washer, ¼” ...................... 4
33 514896 Rear Handle ............................................. 1
— 522388 Switch Service Pack (incl. 34-34A) ..... 1
34 † Switch....................................................... 1
34A 515107 Switch Key ............................................... 1
35 515547 Leg Cap, Right ........................................ 1
36 515552 Wiring Harness....................................... 1
36A 522323 Wire Cover .............................................. 1
36B 515555 Self-Tapping Screw ............................... 1
37 515546 Right Leg.................................................. 1
38 515554 Leg Cap, Left .......................................... 1
39 515664 Left Leg.................................................... 1
40 51481208 Snap-In Plug ............................................ 8
41 515138 Truss Head Screw ................................ 14
42 120214 Lock Washer .......................................... 14
43 102634 Nut, 5/16”-20 ........................................... 14
44 514807 Wheel Retainer ....................................... 2
45 514806 Wheel........................................................ 2
46 514755 Wheel Shaft ............................................. 1
47 51478902 Base Pan .................................................. 1
48 514805 Caster....................................................... 2
— 514890 Attachment Kit (Incl. 49-56) .................. 1
49 514825 Extension Wand...................................... 2
— 514929 Inlet Pug Assembly (Incl. 50-51) ......... 2
50 514824 Inlet Plug .................................................. 2
51 514928 Cap ............................................................ 2
52 514826 Floor Pickup ............................................ 1
53 514828 Elbow Brush ............................................ 1
54 300004 Hose.......................................................... 2
55 300007 Reducer
(Optional - Only needed when used with MKV 500)
56 514829 Utility Pickup ........................................... 1
57 515670 Power Cord ............................................. 1
58 515126 Star Washer ............................................ 2
59 513897 Hex nut, #10-32........................................ 2
†Not available as a service part.
1 514808 Filter Hood ............................................... 1
— 514809 Retaining Strap Asmy. (Incl. 2-4) ........ 1
2 514856 Strap, Metal ............................................. 1
3 514966 Rack .......................................................... 1
4 514855 Clamp ....................................................... 1
— 515595 Main Housing Asmy. (Incl. 5-29) ......... 1
5 515689 Main Housing w/Warning Label .......... 1
6 515561 Self tapping Screw ................................ 4
7 515534 Support Bracket ..................................... 1
— 515596 Motor & Blower Asmy.
(Incl. 8-20)..... 1
8 515549 Inlet Seal .................................................. 1
9 515562 Self-Taping Screw, ¼-20x3/4” ............. 6
10 515533 Fan Housing ............................................ 1
11 515112 Hex Head Cap Screw, ¼-20x1” ............ 1
12 120392 Flat Washer, 3/8” .................................... 4
— 515287 Fan Assembly (incl.11, 13-14) .............. 1
13 † Fan
14 120392 Flat Washer ............................................. 1
15 513627 Hex Head Cap Screws, 3/8-6x1” .......... 4
16 120388 Flat Washer ............................................. 4
17 515535 Motor Housing........................................ 1
18 515248 Key, Square, 3/16” .................................. 1
19 515690 Motor w/plug .......................................... 1
19A 515563 Connector ............................................... 1
19B 515586 Strain Relief ............................................. 1
19C 514881 Screw ....................................................... 2
20 515550 Motor Seal ............................................... 1
21 515137 Self-tapping Screw ................................ 2
22 514832 Self-Tapping Screw, #10-16x1/2” ........ 4
23 514817 Cover Plate .............................................. 1
24 515562 Self-Tapping Screw ............................... 4
25 51476702 3-way Inlet ............................................... 1
— 521769 Handle Package (Incl. 25A-25B) ........... 1
25A 521761 Handle....................................................... 1
25B 521762 Screw ....................................................... 2
26 515555 Self-Tapping Screw ............................... 6
27 515553 Cable Clip................................................. 1
28 515219 Bag Clip .................................................... 3
Ref. Part Item
No. No. Description Qty.
Ref. Part Item
No. No. Description Qty.
Manufacturer: Shopsmith, Inc.
6530 Poe Avenue
Dayton, Ohio 45414
937/898-6070
937/890-5197 Fax
Part Number: 330002
Description: Shopsmith Air FIltration System DC3300
