complete and the BMS01 unit will beep several times, the light will
turn solid green, and then power off within 30 seconds. Important-
after charging is complete disconnect the charger from the battery to
help maintain a high state of charge.
1
When the AC power cord is first plugged to AC power, each LED
will turn on solid, to indicate charger READY for input. Note- If a
button is not pressed within 30 seconds the charger will power down.
2
When the LFX battery is above 50% capacity at the START of
CHARGING, only the Green LED will flash. However, if the LFX is
below 50% capacity at the start of charging, the yellow and green
LED will flash alternately. This warns you that the battery has been
allowed to drop low in voltage, and that you may need to charge more
often, or use the Store Mode while parked long term. To correct this
condition press the charge button, a “triple” beep indicates the charger
is active and the lights continue to alternate. Once the battery reaches
50% + capacity the charger returns to flashing green only.
3
Errors are indicated by a flash/pause sequence of both LED together
An alarm buzzer may also sound until error is corrected or power off:
1 flash/pause = Internal input voltage error. Check that AC
power is in range and properly connected. Try another outlet.
2 flashes/pause = Polarity error. Not typical.
3 flashes/pause = Open Circuit. Charge cables not properly
connected, broken, or worn. Inspect and/or try new cable set.
4 flashes/pause = Battery/Cell voltage error. Cell variation
issue, use the store mode for 24hrs, then charge to correct issue.
WARRANTY (ShoraiDirect.com
)
All warranty claims for products sold via SHORAI DIRECT are
handled directly and ONLY by Shorai Direct, and WILL NOT be
serviced by any other seller or provider of Shorai Products.
For online submission of warranty claims visit:
www.shoraidirect.com/rma
The Serial# and QC decals on the charger MUST be retained in order
to receive warranty service, according to the purchased warranty
level. Do not remove or cover these decals, please.
Please do NOT return any product without an RMA#, or before Shorai
Direct has contacted you to perform some simple diagnostics. In many
cases issues can
be solved prior to return.
Conditions which may not be covered
• Physical Damage to the charger
• Over-voltage input or DC input
• Use with other than Shorai LFX Battery
• Improper connections to the 5-pin BMS port
• Connection or Short Circuit of the Factory Data Port
SHIPPING
DAMAGE
Any item damaged in transit must be reported to the SHIPPER
IMMEDIATELY upon opening of the package, and also Shorai
Direct. All original packaging must be retained until further notice.
Shorai Direct will respond with instructions after consultation with
the shipping agent.
Thank you for choosing Shorai! We hope and expect that you’ll
be pleased with the performance of the products, for years to come.
General inquiries: shop@shoraidirect.com
Tech questions: tech@shoraidirect.com
1x Yellow & 1x Green LED, Buzzer
100V~250V , 50/60Hz, single phase AC
11.4 x11.4 x 3.8cm (4.5 x 4.5 x 1.5”)
